Tile Polishing Machinery LBV/600 G

Tile polishing machinery LBV/600 G Our machine mod. LBV/600 G allows to polish or grind strips of granite. Its structure is composed of a normalized grinded base made of electro-welded steel, and of a moving bridge made of stiffened steel. The single, cast iron operating heads are positioned on the bridge. High stability, accuracy of processing and absence of vibration are guaranteed. The mechanical and electrical components of the machine guarantee high accuracy and reliability, even if used till high stress. All the feeding pipes, the nozzles and the plate casings are dimensioned to supply an adequate water inflow, for a good dressing of the tools during the processing phases, a good quality of cut, and a long tool life. The machine is supplied with grommets to lift the whole structure, while its non-deformability is guaranteed. The electric board is built with steel plate, thickness 15/10, painted with RAL 7032. Its degree of protection is IP 55. An insulated transformer for 380V network voltage and output 48V is installed inside the electric board for all the control bodies to guarantee the safety of the operator in case of breakdown. All the motor protective devices (fuses, magnetothermics and thermal relays) are dimensioned for each single motor to intervene in case of anomaly to protect it.
