SIRIO Automatic Bridge Polishing Machine
FOB Price:
Type:
Stone Factory MachinesStone Surface Processing Machines Bridge Polishing Machine for Slabs
Usage:
Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation, Third-party team installation
Maintenance:Remote troubleshooting
Supplier
Main Product:
Sawing Bridge Machines, Polishers, Lathe Machine, Block Cutter, Bridge Saw Machines, CNC Machine, Calibrating Machine, Waterjet Machine, Wire Saw|
Machinery Function Features
SIRIO AUTOMATIC BRIDGE POLISHER
For marble and granite slabs with electronic control of the movements. The polishing machine SIRIO is the basic tool for any factory in stone processing.
FEATURES
The basic version can polish:
- marble slabs using the head with Frankfurt type abrasives;
- granite slabs using:
- the optional satellite head with circular grinding wheels with TERZAGO Brevetti couplings;
- fickert type TANGENTIAL abrasive head.
The plate for marble can be applied on the satellite head with Frankfurt type abrasives.
OPTIONAL
Satellite head head for granite.
Tangential head for granite.
Head for marble.
Bush-hammering plate.
Camera
Tilting table ( one or more )
Support for 4 heads Astro automatic change
Bush-hammering plate (only if the head is not autmatic)
Technical Data
Parameters |
Unit |
SIRIO |
Machine overall width |
mm |
7200 |
Slabs max. polishing width |
mm |
2950 |
Production capacity for granite slabs |
mq/h |
3÷4 |
Production capacity for marble slabs |
mq/h |
6÷8 |
Rotation speed of the head |
rpm |
0/700 |
Structure travel speed |
mm/min |
0÷32 |
Power of conveyor belt motor |
kw |
2,1 |
Spindle beam travel speed |
mm/min |
0÷32 |
Cooling water consuption at 3 bar |
l/min |
40 |
Air consumption at 3 bar |
l/min |
340 |
On request track of different lengths (multiples of 3 m) |
m |
9-12 |
Power of spindle beam motor |
kw |
18,5 |
Machine overall length |
mm |
6600 |
Machine overall height |
mm |
3200 |
Length of standard tracks |
m |
6 |
Pneumatically regulated working pressure |
bar |
6 |
Belt advancement speed |
mm/min |
0÷32 |
Approx. Weight |
Kg |
5000 |
Slabs max. processable length |
mm |
4300 |
Current voltage / frequency |
V / Hz |
400 / 50 |
Polishing spindle vertical travel |
mm |
300 |
