Mitre Saw MANTA INOX 85 Tile Cutting Machine
FOB Price:€2795-2795
Type:
Stone Factory MachinesStone Tile Cutting MachinesMitre Saw, Edge Cutting Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Remote guidance installation
Maintenance:Remote troubleshooting
Machinery Function Features
Construction site saw MANTA INOX 85
€ 2,795.00 *
excl. VAT plus shipping costs
Available again soon
Product number: O16.100
description
Product information "construction site saw MANTA INOX 85"
for cutting tiles, natural stone, cast stone slabs and other building materials
latest generation of mobile stone saw with powerful motor, stainless steel tub, mini battery laser and stop
very robust and durable construction
full-surface support table for thin workpieces
precise cuts thanks to the 40 mm diameter precision round guide with recirculating ball bearings
more stability thanks to machine feet with cross bracing
Easily transportable thanks to the folding machine feet and transport wheels (with a cutting length of 1500mm, rigid feet)
Bore 25.4 mm, power 2.6 kW with motor brake / 230 V | Galvanized swivel element, infinitely adjustable 45-90 degrees | Height adjustment via M24 threaded rod with large handwheel
Dimensions (L / W / H): 1,400 x 660 x 770 mm
Speed: 2,800 rpm
Weight: 96 kg
Cutting length: 850 mm
Cutting depth: 60/80/110 mm
Cutting disc ø: 250/300/350 mm
Technical Data
Parameters |
Unit |
MANTA INOX 85 |
Diamond blade diameter |
mm |
250/300/350 |
Max. cutting spindle tilting angle |
° |
45-90 |
Cutting depth |
mm |
60/80/110 |
Main motor rotation speed |
r/min |
2800 |
Machine width (W) |
mm |
660 |
Approximate weight |
Kg |
96 |
Standard voltage |
V |
230 |
Machine length (L) |
mm |
1400 |
Max. cutting length |
mm |
850 |
Machine height (H) |
mm |
770 |
Blade bore size |
mm |
25.4 |
Main motor power |
kw |
2.6 |
