Automatic Litchi Noodle Machine- Bush Hammering Machine
FOB Price:$10000-10500
Type:
Stone Factory MachinesStone Surface Processing Machines Bush Hammering Machine
Usage:
Granite, Marble, Limestone, Slate, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time:
20 days
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Regular guidance & maintenance, Remote troubleshooting
Machinery Function Features
Full-automatic continuous litchi noodle mill, based on the principle of continuous walking, through the improvement of grinding head and program conversion, becomes a new type of continuous litchi noodle machine. The operation control system adopts PLC terminal control, and the parameter setting is carried out through the LCD touch screen. Grinding and polishing adopts pneumatic control, and its pressure is adjustable within the set value. This litchi noodle machine can automatically identify the thickness of the plate, the processing process is safe, the processing effect is uniform, the plate is not easy to break, and it saves labor.
Technical Data
Parameters |
Unit |
ZL-1200/6 |
ZL-1200/8 |
Beam swing speed |
m/min |
3-35 |
3-35 |
Main motor power |
kw |
5.5 |
5.5 |
Max. processing thickness |
mm |
100 |
100 |
Total power |
kw |
36 |
47 |
Min. processing thickness |
mm |
10 |
10 |
Machine overall width |
mm |
2700 |
2700 |
Bush hammer disk diameter |
mm |
200 |
200 |
Approx. Weight |
Kg |
4000 |
5500 |
Water consumption |
m3/h |
6 |
8 |
Gas supply pressure |
mpa |
0.8 |
0.8 |
No. of hammering head |
nr |
6 |
8 |
Machine overall height |
mm |
2300 |
2300 |
Min. Cooling water pressure |
Mpa |
0.1-0.5 |
0.1-0.5 |
Machine overall length |
mm |
4500 |
5200 |
Into the plate velocity |
m/min |
1-4 |
1-4 |
Max. processing width |
mm |
1200 |
1200 |
