MKD- 2012 -BL CNC Machining Center
FOB Price:
Type:
Stone Factory MachinesStone Finishing, Profiling MachinesCNC Working Center
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation, Third-party team installation
Maintenance:Online software upgrade, Remote troubleshooting, Field troubleshooting
Supplier
Eatablished :Feb 01,2012
Main Product:
CNC Machines|
Machinery Function Features
As one of the glass and rock plate CNC machining center manufacturers, MKD has always been committed to developing mid-to-high-end products, and is distinguished from other brands by its superior design and reliability.
MKD's manufacturing philosophy: ingenuity to manufacture high quality.
The design purpose of MKD CNC: to process high-quality products with the shortest preparation time and fast axis moving speed, the full digital operation and control system improves the response speed and precision of each axis, with high precision, high quality and high efficiency for Final goal.
Technical Data
Parameters |
Unit |
MKD-2515 |
MKD- 2015 |
MKD-2012 |
Max. working thickness |
mm |
19 |
19 |
19 |
Power demand |
AC380V+5%50~ 60HZ |
AC380V+5%50~ 60HZ |
AC380V+5%50~ 60HZ |
|
Standard voltage |
Volt |
380V 50HZ |
380V 50HZ |
380V 50HZ |
Tool-holder spindle motor power |
kw |
11 |
11 |
11 |
Min. working thickness |
mm |
3 |
3 |
3 |
Rail configuration |
Taiwan Shangyin 35 square rail |
Taiwan Shangyin 35 square rail |
Taiwan Shangyin 35 square rail |
|
Repeat positioning accuracy |
mm |
0.02 |
0.02 |
0.02 |
Empty travel speed |
mm/min |
18000 |
18000 |
18000 |
Dimensions of the work table (length x width) |
mm |
2500*1500 |
2000*1500 |
2000* 1200 |
Tool-holder spindle rotation speed |
r/min |
12000 |
12000 |
12000 |
Max. diameter of the blade |
mm |
100 |
100 |
100 |
Total Power required |
kw |
25 |
25 |
25 |
Processing accuracy |
mm |
± 0.05mm/300min |
± 0.05mm/300min |
± 0.05mm/300min |
