Wisdom Edge Polishing Machine For Stone Marble Granite
FOB Price:$8000-8000
Type:
Stone Factory MachinesStone Finishing, Profiling MachinesEdge Profiling, Polishing Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time:
30days
Warranty:12 Months
Install and Guarantee:Remote guidance installation
Maintenance:Regular guidance & maintenance, Remote troubleshooting
Supplier
Eatablished :Jan 20,2021
Main Product:
Bridge Saw, Stone Cutting Machine, Block Cutting Machine, Wire Saw Machine, Stone Splitter, Stone Polishing Machine|
Machinery Function Features
This machine process each kinds of linear-shaped and curved-shaped edge function.This machine is with oil-bath up-place type sealed guide rail.It uses frequency converter to conduct step less speed adjustment.The vertical of the ram equipped with automatically and manual functions.By transverse stoke,load powerful,the stability is good,the service life is long,cost low status merit,the processing feeds speed between5.5～0.6m/min.May establish willfully for all kinds processing,by satisfies each kind of processing to need.This machine also designed has been automatic,manual double movement fluctuation,it enormous reduces worker's labor in tensity and raise working efficiency.
Technical Data
Parameters |
Unit |
WSDEP |
the main motor power |
kw |
7.5 |
the diameter of saw blade |
mm |
160-180 |
the pressure of the water |
mpa |
0.2 |
overall dimensions |
mm |
4350x2300x960 |
Max cutting length |
mm |
3500 |
the table size |
mm |
4000x500 |
the diameter of milling wheel |
mm |
140-160 |
Milling head vertical moving motor |
kw |
0.18 |
the gross power |
kw |
9.18 |
Milling head transverse moving motor |
kw |
1.5 |
Max cutting thickness |
mm |
150 |
exhausted water |
m³/h |
2 |
gross weight |
kg |
2600 |
Processed Stone Photos
Components
Consumables
