Multi Wire Saw Machine 36 ADVANCED
FOB Price:$100000-400000
Type:
Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time:
-
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Regular guidance & maintenance, Remote troubleshooting, Field troubleshooting
Supplier
Eatablished :Dec 31,1989
Main Product:
Stone Machinery|
Machinery Function Features
Karann Multi Wire Saw Machine
Our different machine models between 10-36 wires
Made by Turkey
There are 3 different versions of our machine
5 wire 2 cm slabs
10 wire min 5 cm slabs (for thick stone with separate hoops each)
36 wire 2 cm slabs
Technical Data
Parameters |
Unit |
Multi Wire ADVANCED 5-10-15-36 |
Slabs nominal thickness |
mm |
1.9-2.1 2.9-3.1 |
Machine width (W) |
mm |
6.630 mm |
Main motor power |
kw |
160 |
Dim. Trolley Size/Worktable size |
mm |
2.600mm * 2.400mm |
Max. Cutting width |
mm |
6.630 mm |
Max. individual diamond wire tension |
Kg |
180-220 |
Worktable load capacity |
T |
36 |
Cooling water(min. required pressure 3.5 bar) |
L/min |
540 |
Machine height (H) |
mm |
7000 mm |
Production efficiency 20mm thick. |
m2/h |
2.5 |
Max. Cutting length |
mm |
10.200 mm |
Machine length (L) |
mm |
10200 mm |
Diamond wires speed |
m/s |
10 - 45 meters/second (depending on the stone) |
Max. Cutting height |
mm |
7.000 mm |
Wires set width |
mm |
2-3 and 5-10 |
Diamond bead diameter |
mm |
6,3-7,3 |
Voltage/Frequency |
V/Hz |
380V 50 Hertz |
Approximative Weight |
T |
33 |
Installed electrical power |
kw |
182 |
Diamond wire length |
mm |
20000 |
Fast lowering unit power |
kw |
7.5 |
Software
11” GMT/DELTA dokunmatik PLC sistemi. Türkçe ve İngilizce / touch PLC system. Turkish and English
Control Unit: Schineider
İnverter control: Delta
Processed Stone Photos
Components
-
wire
¥Payment Required
Consumables
-
polyurethane
Video
Operation Video
