Automatic Slabs Loader Unloaded Machine
FOB Price:$3000-5000
Type:
Stone Factory MachinesStone Handling, Loading MachinesAutomatic Loader, Unloader for Slabs
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time:
7 days after receiving deposit
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation, Third-party team installation
Maintenance:Online software upgrade, Regular guidance & maintenance, Remote troubleshooting, Field troubleshooting
Machinery Function Features
Introduction of Automatic Slabs Loader Unloaded Machine
Automatic Slabs Loader Unloaded Machines are mainly for automation products with high labor costs, and difficult, safe, and efficient construction. The product is mainly pneumatically lifted and joined with a vacuum chuck. A fully automatic upper plate machine and lower plate equipment, the main supporting equipment, can be equipped automatic polishing machine. automatic machine and automatic grinding roadside machine to form an integrated assembly line operation, saving labor costs, and safe and practical.
The benefit of using Automatic Slabs Loader Unloaded Machine
Improve work efficiency: Fully automated operation can be achieved without manual participation, thereby improving work efficiency.
Reduce labor intensity: It can replace manual repetitive labor, thereby reducing labor intensity and improving the safety of the working environment.
Improve product quality: It can ensure that the plates are not damaged during loading and unloading, thereby improving product quality.
Cost savings: Labor costs and equipment maintenance costs can be reduced, thereby saving costs.
Technical Data
Parameters |
Unit |
DFL-M1000 |
Number of suction cups |
piece |
200x300 |
Vacuum pump specifications |
m3/h |
20 |
Rolling Table Dimensions (WxL) |
mm |
1200x 2500 |
Suction cup shaft length |
mm |
4 |
Voltage |
hz/v |
50hz, 380v |
Working thickness |
mm |
150 |
Front and back row |
mm |
1800 |
Equipment load |
kg |
150 |
Up and down stroke |
mm |
1300 |
Maximum size of adsorption plate |
mm |
800x2400 |
Suction cup size |
mm |
10-50 |
Suction speed |
minute |
2 sheets |
Total power |
kw |
3 |
The minimum size of the adsorption plate |
mm |
400 x400 |
