Combination Rope Saw Machine
FOB Price:$8000-15000
Type:
Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time:
35 day
Warranty:12 Months
Install and Guarantee:Customer pay for installation
Maintenance:Remote troubleshooting, Field troubleshooting
Trade Terms
Port:
Xiamen- China
Delivery Details: FOB,CFR,CIF,DDP,DDU
Payment :
Supplier
Eatablished :Jun 17,2006
Main Product:
Countertops, Benchtops, Worktops, Slabs, Tiles, Tombstones|
Machinery Function Features
Combination Rope Saw Machine
Technical Data
Parameters |
Unit |
MWS5B |
Slabs Thickness |
mm |
80/100/150/180/200/300 |
Idler Wheel Diameter |
mm |
Φ1200 |
Max.Cutting Size |
mm |
3000*2000*1000 |
Max.Wire Quantity |
5 |
|
Cooling Water |
L/min |
250 |
Motor Wheel Diameter |
mm |
Φ1200 |
Dimension(L*W*H) |
mm |
9000*3300*6400 |
Wires Speed |
m/s |
0-35 |
Lifting Speed |
cm/min |
0-30 |
Wire Length |
m |
18.17 |
Lifting Stroke |
mm |
2200 |
Wires Tension |
kgf |
260-300 |
Main Motor Power |
kw |
37 |
Installed Electrical Power |
mm |
45 |
Wire Diameter |
mm |
Φ8.8 |
Processed Stone Photos
Components
Consumables
Video
Install Video
Operation Video
