S1530B CNC ROUTER CARVING MACHINE FOR STONE
FOB Price:
Type:
Stone Factory MachinesStone Finishing, Profiling MachinesStone Carving,Engraving Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Supplier
Eatablished :Feb 15,1998
Chen Chengjun
Main Product:
Cnc Router Machine, Stone Engraving Machine, Marble Carving Machine, Granite Engraving Machine, Bluestone Cnc Machine, Gritstone Machine|
Machinery Function Features
Chencan S1530B is one type big size cnc carving machine for stone with heavy duty design. we offer customer-designed service, you just need to tell us your requirements or the workpiece size, materials and we’ll give our suggestion.
Features
•3 axis with dust proof;
•6 wheels on the front of the table, make the load heavy stone easy;
•With wheels in front for easy put on material;
•#25 Taiwan Linear guide and high precision ball screw;
•Water tank with water cooling sprayer to cool the tool when working;
•Table Structure and T-slot table with 25mm hard PVC;
•Transmission system: X,Y axis Gear Rack and z axis Ball screw from Taiwan but with German technology;
•Lead rail system: Taiwan Linear round guide rail;
Technical Data
Parameters |
Unit |
S1530B |
Max. processing length |
mm |
1500 |
Repeated positioning/Ball screw precision |
mm |
0.2 |
Control System |
Original NK105 [NC Studio and DSP is optional] |
|
Motor |
YAKO easy servo motor(stepper/Yaskawa servo optional) |
|
Compatible file formats |
G code ; *.u00 ; *.mmg ; *.plt |
|
Main spindle motor power |
kW |
6 |
Main spindle speed |
r/minute |
0-18000 |
Compatible Softwares |
Ucancam V8 / Artcam |
|
Drive |
YAKO easy servo driver |
|
Software environment |
Windows 98/2000/XP |
|
Working Voltage |
V/Hz |
AC380V, 3ph, 50Hz |
Max. working speed |
m/min |
15 |
Max. Processing Width |
mm |
3000 |
Max. processing thickness |
mm |
300 |
Processed Stone Photos
