OZTKM 5/10/20/40 Multiwire Cutting Machine, Multi Wire Saw Machine

Name: OZTKM 5/10/20/40 Multiwire Cutting Machine, Multi Wire Saw Machine
Brand: Ozteknik Makine
SKU: 1855
Price: 10000 USD
Availability: InStock

FOB Price:

Type: Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine

Usage: Granite, Marble, Limestone, Sandstone, Travertine

After-Sale

Warranty:12 Months

Install and Guarantee:Customer pay for installation, Remote guidance installation

Maintenance:Remote troubleshooting, Field troubleshooting

Supplier

Ozteknik Makine

Ozteknik Makine

Turkey

Eatablished :Jan 01,1979

Main Product:

Stone Machinery, Cutting Machine, Polishing Machine, Wire Saw|

Contact supplier

Start Order

You may also like

TSY-MW 50/52 Skystone Multi Wire Saw Machine With CE Certification

MULTI-WIRE SAW MACHINE

Multi Diamond Wire Saw Machine For Marble And Granite Block Cutting

Multi-Wire Saw Machine For Granite And Marble Blocks Sawing

Granite Block Diamond Multi Wire Saw Cutting Machine

Product Detail
Company Profile

Overview

Machinery Function Features

Simple and Strong Structure: Özteknik multiwire machine has an open frame structure which is both strong and functional. All parts undergo thorough structural checks with the aid of Computer Aided Engineering (CAE) software. Two columns are robustly fixed to foundation and one connecting transversal beam that have been built with wide closed section in large thickness normalized steel work. The weight on nuts, which are caused by the effect of the operational elements connected to sliders, are supported with N2 pistons in the columns. Utilizing two columns makes accessing the machine very convenient. The wires can be replaced or moved to obtain different thickness requirements very quickly and smoothly as the machine can be easily accessible from all sides. Low Maintenance Cost: Özteknik multiwire cutting machine possesses low operating and maintenance costs and our company ensures the delivery of spare parts to meet the needs of the user at reasonable prices. Due to the design practices employed during the

Technical Data

Parameters	Unit	OZTKM 5/10/20/40
Machine height (H)	mm	3200
Max. Cutting height	mm	2200
Main motor power	kw	160
Diamond wires speed	m/s	20-35
Max. Number of wires for sawing 20mm thick.	nr	5/10/20/40
Machine width (W)	mm	5100
Number of wire	pcs	20
Max. Cutting length	mm	3500/3700
Machine length (L)	mm	7200
