Skystone Down The Hole Drill Machine
FOB Price:
Type:
Stone Quarry MachinesQuarry Drilling MachineElectric Horizontal Drill Machine
Usage:
Granite, Marble, Limestone, Quartzite, Sandstone
After-Sale
Warranty:12 Months
Install and Guarantee:Remote guidance installation
Maintenance:Regular guidance & maintenance, Remote troubleshooting, Field troubleshooting
Trade Terms
Delivery Details: FOB,CFR,CIF,EXW
Payment :


Machinery Function Features
The mechanical design is reasonable, convenient, easy to hoist, and can be operated in a small space.
The equipment is easy to assemble, easy to operate, and save time.
The machine is convenient for hoisting,which is especially suitable for fast positioning and drilling in narrow space corners.
Pneumatic and hydraulic dual power makes the equipment ultra-high efficiency and stable operation, making drilling operations safe, efficient and stable.
Reasonable layout of equipment accessories makes equipment maintenance simple and low-cost.
The equipment has strong adaptability and can meet the different drilling needs of customers.
24-hour professional technical guidance and consultation make use without worries.
Technical Data
Parameters |
Unit |
TSY-PH90A |
Max spin pressure |
MPa |
12.5 |
Supply voltage |
V/Hz |
380/50 |
Air pressure |
MPa |
0.5~0.7 |
Drill speed |
m/h |
5~10 |
Max traveling pressure |
MPa |
8 |
Drill depth |
m |
30 |
Rotated motor power |
kW |
5.5 |
Air consumption |
m³/min |
≥6 |
Bit diamater |
mm |
ф90~ф100 |
Single drill distance |
m |
1.71 |
