MPM Mini Jet Digital Printer For Ceramic, Porcelain, Sintered Stone

FOB Price:

Type: Artificial Stone MachinesPrinting, Decorating Machine
Usage: Artificial Stone
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation, Third-party team installation
Maintenance:Online software upgrade, Regular guidance & maintenance, Remote troubleshooting, Field troubleshooting

Supplier

Eatablished :Jan 01,1993

Main Product:

Ceramic Machinery, Ink Jet Printing Machine, Glazing Line Machines|

Contact supplier

Start Order

  • Overview
Machinery Function Features
Mini jet is developed specifically for wall tile production line. It is very compact with full-featured. The up-to-date double belt has been designed according to innovative criteria, there will not affect the glaze line production any more during the machine’s maintenance or sample testing etc. It’s equipped with the same XAAR print heads ,mature ink system and print system with King jet’s, so as to provide more and better choice for customer because of high quality and more economic price. Advantages: 1.Compact design for less space occupation. 2.Double belt for tile conveying with built-in by-pass. 3.Six-bar standard design prepared for color expansion in the future. 4.In-line sampling with optional dual entry large output printing. 5.Pull-out style ink tank trolley for easy maintenance.
Technical Data
Parameters
Unit
MPM-490
MPM-512
Total Power
kw
10~15
10~15
Machine overall height
mm
1250
1250
Max. Tile Thickness
mm
30
30
Print type
XAAR Binary/Gray Scale(8 level)
StarFire Binary/Gray Scale(4 level)
Machine overall length
mm
3430
3430
Number of print head
nr
3 / 4 / 5 / 6 / 7
4 / 5 / 6 / 7 / 8
Number of colour bars
nr
4 / 5 / 6
4 / 5 / 6
Printable width
mm
210 / 280 / 350 / 420 / 490
256 / 320 / 384 / 448 / 512
Height of conveyor belt
mm
1100+/- 50
1100+/- 50
Max. printing speed
m/min
XAAR2001 <48 / XAAR1003 <24
StarFire SG1024/ SG600-SC<50
Machine overall width
mm
1750
1750
Useful printing width
mm
70
64
Brand and model of printheads
XAAR(2001/1003) GS6/GS12/GS40
StarFire:SG1024 SC/MC/LC, SG600-SC
Resolution
dpi
XAAR2001:720 dpi/ XAAR1003:360 dpi
StarFire SG1024: 400 dpi / StarFire SG600-SC: 600 dpi
