Movable Mono Wire Saw Machine

Name: Movable Mono Wire Saw Machine
Brand: FUJIAN SKYSTONE TECHNOLOGY CO., LTD.
SKU: 6960
Price: 10000 USD
Availability: InStock

FOB Price:

Type:

Usage: Granite, Marble, Limestone, Sandstone

After-Sale

Lead Time: 3 months

Warranty:12 Months

Install and Guarantee:Remote guidance installation

Maintenance:Regular guidance & maintenance, Remote troubleshooting, Field troubleshooting

Trade Terms

Port: Xiamen- China

Delivery Details: FOB,CFR,CIF,EXW

Payment :

Supplier

FUJIAN SKYSTONE TECHNOLOGY CO., LTD.

Skystone

China level 6YR

Eatablished :Jan 01,2003

Main Product:

Stone Tool, Wire Saw Machine, Quarry Machine, Drilling Machine, Diamond Wire Saw, Wire Saw|

Contact supplier

Start Order

You may also like

Movable Mono Wire Saw Machine TSY-MWB4000

500 Bar Water Blast Cleaning Machine High Pressure Hydro Blasting

Multi-Functional Four Hammer Rock Driller - Quarry Drilling Machine

Popular 6 Axis Robotic Arm For Mold Furniture Industry In Germany DE

HLMJD Fully Automatic Marble / Granite Polishing Machine

Product Detail
Company Profile

Overview
Components
Trade Terms
Customer Case

Machinery Function Features

The mono-wire machine are expressly designed for for different stone blocks trimming and thicker slab cutting .Multiple blocks can be loaded for automatic cutting by PLC control ,greatly reduce the labor cost in European market, with a localized service team, can provide convenient and fast react market services.

Technical Data

Parameters	Unit	TSY-MWB4000
Rail length	m	6
Diamond wire linear speed	17	0-40
Machine weight	t	8.5
Machine height (H)	4	5700
Machine Width (W)	4	3200
Machine length (L)	4	8900
Cooling water requirements	32	31
Block max. cutting width	4	4000
Diamond bead maximum diameter	4	8.3-11
Total power	kw	24.25
Main motor power	7	18.5
Block max. cutting height	4	2200
Movable range	m	3.1
Diamond wire length	4	19.65
