Multi-Functional Four Hammer Rock Driller - Quarry Drilling Machine
FOB Price:$5500-13500
Supplier
Eatablished :Apr 13,2017
Main Product:
Stone Machinery, Stone Cutting Machine, Stone Polishing Machine, Stone Profiling Machine, CNC Bridge Saw, Stone Engraving Machine|
Multifunctional Rock driller is mainly used in quarrying, available for horizontal, vertical, and slantwise drilling . And used for dividing large blocks into smaller ones.
Parameters |
Unit |
YT29A |
2-YT29A |
4-YT29A |
Advance power |
kw |
1.5 |
3 |
6 |
total compressed air consumption |
m³/min |
7-9 |
10-12 |
18-20 |
total weight |
kg |
500 |
1000 |
1200 |
minimum air pressure |
MPa |
0.6 |
0.6 |
0.6 |
drilling direction |
Any direction |
Any direction |
Any direction |
|
Feed System |
Pneumatic motor, chain |
Pneumatic motor, chain |
Pneumatic motor, chain |
|
max.drilling depth |
m |
1-8 |
1-8 |
1-8 |
drilling diameter |
mm |
34-42 |
34-42 |
34-42 |
rated track length |
m |
2*3 |
2*3 |
2*3 |
cross travel device |
Hand wheel, gear, rack |
Hand wheel, gear, rack |
Hand wheel, gear, rack |
|
track travel |
m |
3 |
3 |
3 |
Single advance |
m |
2 |
4 |
8 |
number of the hammer |
1 |
2 |
4 |
|
drilling speed |
m/h |
30 |
30 |
30 |
Driller Code |
Single Hammer Rock Driller for Vertical and Horizontal Drilling |
Two-Hammer Rock Driller for Horizontal Drilling |
Four Hammer Rock Driller for Horizontal Drilling |
