Double Blade Mining Machine (Standard)

FOB Price:$21500-22000

Type: Stone Quarry MachinesDouble Blade Mining Machine
Usage: Granite, Marble, Limestone, Slate, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time: 30 days
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Regular guidance & maintenance, Remote troubleshooting

Supplier

Eatablished :Apr 13,2017

Main Product:

Stone Machinery, Stone Cutting Machine, Stone Polishing Machine, Stone Profiling Machine, CNC Bridge Saw, Stone Engraving Machine|

Contact supplier

Start Order

  • Overview
  • Components
  • Video
Machinery Function Features
1.It has a compact structure, with mechanical system, hydraulic system and electrical system integrated, high degree of automation, simple operation and easy-to-use feature. 2.The cylindrical guide rail is fully sealed to ensure that the guide rail no pollution and machine has an original lubrication system, so the service life and utilization ratio are effectively increased and maintenance times and costs are reduced. It is a mine quarrying machine with significantly increased comprehensive benefits. 3.Unique cylindrical guide, hydraulic elevator design and super wide chassis, so the structure is more stable and longer useful life. 4.With the super giant saw blades, it can be used for the processing of ultra-large rocks and blocks to improve out turn percentage of the mine and make full use of the mineral resource. 5.Disc saw blades cutting is more secure, environmental, lower cost and more efficient than traditional blasting mining method.
Technical Data
Parameters
Unit
YZK1360/1900-3600
YZK1500/2000-3600
YZK1950/2450-3600
YZK1950/2450-4600
YZK1950/2450-4800
YZK2600/3100-3600
YZK2600/3100-4600
YZK2600/3100-4800
Max Blade Diameter
mm
φ2200*2-φ3600*2
φ2200*2-φ3600*2
φ2200*2-φ3600*2
φ2600*2-φ4600*2
φ2600*2-φ4800*2
φ2200*2-φ3600*2
φ2600*2-φ4600*2
φ2600*2-φ4800*2
Rails Center distance
mm
1140
1290
1670
1670
1670
2200
2200
2200
Water consumption
m³/h
5
5
5
5
5
5
5
5
Approximate weight
kg
7500
7500
9000
10500
11000
11000
12000
12500
Max cutting depth
mm
1500
1500
1500
2050
2150
1500
2050
2150
Overall dimension (L*W*H)
mm
3800*1550*3200
3800*1550*3200
4000*2150*3200
5000*2150*3800
5300*2150*3900
4300*2800*3200
5200*2800*3900
5300*2800*3900
Main Motor power
kw
55*2
55*2
55*2
65*2
65*2
55*2
65*2
65*2
Cutting width
mm
1360-1900
1500-2000
1950-2450
1950-2450
1950-2450
2600-3100
2600-3100
2600-3100
Total power
kw
120
120
120
140
140
120
140
140
Processed Stone Photos
