edge cutting machine small cutter for granite/marble
FOB Price:$4300-4800
Type:
Stone Factory MachinesStone Tile Cutting MachinesMitre Saw, Edge Cutting Machine
Usage:
Granite, Marble, Quartzite
After-Sale
Lead Time:
20days
Warranty:12 Months
Install and Guarantee:Customer pay for installation
Maintenance:Online software upgrade
Supplier
Eatablished :Dec 24,2010
Main Product:
Bridge Cutting Machine , Profiling Stone Line Machine , Wire Saw Machine , Edge Cutting Machine|
Machinery Function Features
JCQ-800 cutting machine
This machine use joint structure, the head can be rotate +-90°, electric lifting, table handle drive, compact structure, stable performance, high accuracy. For small plates, bar board, thick on the edge, chamfer and edge grinding.
JCQ-800A cutting machine
This machine use joint structure, the head can be rotate +-90°, electric lifting, table handle drive, compact structure, stable performance, high accuracy. For small plates, bar board, thick on the edge, chamfer and edge grinding.
Technical Data
Parameters |
Unit |
JCQ-800/800A |
Diamond blade diameter |
mm |
350-500 |
Machine length (L) |
mm |
5400/4200 |
Angle of cutter |
° |
+-90° |
Max stone thickness |
mm |
150 |
Standard frequency |
Hz |
50 |
Approximate weight |
kg |
2000/1800 |
Standard voltage |
V |
380 |
Machine height (H) |
mm |
2000/2400 |
Main motor power |
kW |
7.5 |
Machine width (W) |
mm |
2200/2000 |
Worktable dimensions |
mm |
3200*1000*150/2600*800*150 |
Processed Stone Photos
Components
-
Schneider, Omron
Consumables
