TANK DRILL K21 Mobile Quarry Driller

Name: TANK DRILL K21 Mobile Quarry Driller
Brand: Kur Makina Tic.Ltd.Sti.
SKU: 3363
Price: 10000 USD
Availability: InStock

FOB Price:

Type: Stone Quarry MachinesQuarry Drilling MachineHydraulic Drill Machine

Usage: Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine

After-Sale

Warranty:12 Months

Install and Guarantee:Customer pay for installation

Maintenance:Remote troubleshooting

Supplier

Kur Makina Tic.Ltd.Sti.

Turkey

Eatablished :Nov 10,2004

Main Product:

Quarry Machines, Wire Saw Machine, Chain Saw Machine, Drilling Machine, Mobile Drill Machines, Hydrobag|

Contact supplier

Start Order

You may also like

Quarry Drilling Machine

Crawler Drilling Rig Quarry Drilling Machine

Air Compressor Marble Quarry Drilling Machine

Hydraulic Driller on Track Pct 100 for Quarry

Inwell Rig Light Weight INW-101 Quarry Drilling Machine

Product Detail
Company Profile

Overview

Machinery Function Features

Technical Specs Main Engine = 22 Kw - 30 Hp/1500 Rpm 380 V Rotation Engine = Hrs 400 cc Rotation Pressure = Max 200 Bar Movement System = Movement Motor Push Engine = 50 cc With Gearbox Push Pressure = Max 120 Bar Diesel Engine = 27 Hp 1850 rpm Water Cooling Phase Saver = Included Drill System = Horizontal + Vertical Drill Capacity = Max 60m. Pushing System = Adjustable Pressure Drill Speed = Changeable for hardness 5 – 15min. Hydraulic Tank Capacity = 300 Lt Tower Length = 280 cm Air Consumption = 2,1 M3 / 6 Bar - 4,0 M3 / 10 Bar Compressor = Screw Air Compressor 4,5m3 / 10bar Pipes = 180 cm – 20 pcs Roc+ 21 Dth Hammer Toolbox

Technical Data

Parameters	Unit	TANK DRILL K21
Drill System		Horizontal + Vertical
Hydraulic Tank Capacity	lt	300
Hole diameter Φ	mm	70
Total installed power	kw	22
Usable extension rods length	cm	180 cm – 20 pcs
Height of drill guide	mm	280
Main engine speed	rpm	1500
Screw Air Compressor	bar	4,5m3 / 10bar
Max Drill Capacity	m	60
Air Consumption	bar	2,1 M3 / 6 Bar - 4,0 M3 / 10 Bar
Diesel Engine Power	hp	27 Hp/ 1850 rpm
Max. Push Pressure	bar	120
Max. Rotation Pressure	bar	200
