TAURUS 565 Edge Polishing Machine
FOB Price:
Type:
Stone Factory MachinesStone Finishing, Profiling MachinesEdge Profiling, Polishing Machine
Usage:
Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation, Third-party team installation
Maintenance:Remote troubleshooting
Supplier
Eatablished :Dec 30,1983
Main Product:
Machines For Granite Marble, Edge Polishing Machine, Used Machines, Polishing Machine, Edge Profiling In Line, #V-Groove|
Machinery Function Features
TAURUS 565
COMPACT WITH GREAT PERFORMANCES
Behind the Taurus 565 edge polishing machine there is an advanced technological study that ranges from the realization of different projects, from a simple staircase step to a kitchen countertop.
Technical features that distinguish it:
calibration device with the possibility of calibrating a width of 60 mm;
blade cutting, drip tray and inclined cuts;
6 frontal polishing heads and 5 abrasive heads;
floating system for polishing granite;
patented system that allows the execution of the processes without the help of the feedback bar;
latest generation lubrication system with automatic monitoring of greasing times and failure reporting.
Technical Data
Parameters |
Unit |
TAURUS 565 |
Approx. Weight |
Kg |
5000 |
Max. diameter of calibrating wheel |
mm |
200 |
Standard diameter of chamfering wheels |
mm |
130 / 150 |
Diameter of the drip board saw blade |
mm |
300 |
Water consumption |
L/min |
90 |
Machine overall width |
mm |
1800 |
Machine overall length |
mm |
5000 |
Total power |
kw |
30 |
Number of dressing/polishing spindles |
nr |
6 |
No. calibrating/shaping/cutting spindles |
nr |
6 |
Machine overall height |
mm |
2000 |
Min. processing thickness |
mm |
15 |
Belt advancement speed |
mm/min |
5 / 2300 |
Standard diameter of polishing wheels |
mm |
130 / 150 |
Number of Bevelling/chamfering spindles |
nr |
2 / 4 |
Max. processing thickness |
mm |
60 |
Grinding tool diameter |
mm |
130 / 150 |
