EVO 3/5/7 Digital Decorating Machines EVOLVE/EVO PLUS

Enriched with new models and fittings, the Evolve family of digital decorators is by far the most complete and versatile on the market, able to express an impressive color space or enhance the new materials and new digital ceramic effects thanks to the new Evoplus versions. EVOSEVEN able to house up to 7 color modules EVOFIVE able to house up to 5 color modules EVOTHREE able to house up to 3 color modules Main advantages: COMPACTNESS AND DUCTILITY EASE OF ACCESS AND MAINTENANCE THANKS TO THE AUTOMATIC CLEANING SYSTEM ENHANCED SUCTION MANAGEMENT OF MACHINE PARAMETERS FROM SINGLE POINT LOW POWER INSTALLED SPEED OF IMAGE LOADING UP TO 7 COLOR BARS IN AN EXTREMELY CONTAINED SPACE Number of color bars: 3 Printing area: 700 mm Resolution: 360 x 360 dpi at 24 m / min Resolution: 360 x 360 dpi at 48 m / min * Maximum printing speed: above 50 m / min Variable drop dimensions: up to 8 levels of greyscale Print type: Inkjet drop on demand Brand and model of printheads: XAAR 1001 GS6 / GS12 * Belt conveyance by means of brushless motor with optical encoder and reduction unit with zero clearance Belt width: 750 mm Power supply: 400 VAC Three-phase 50 Hz + N + T Power: 5 kW Filtered compressed air: min. 6 bar Machine footprint (L x D x H): 2200 mm x 1500 mm x h 2000 mm Conditioned booth footprint (L x D x H): 4100 mm x 2800 mm x h 3000 mm
