SQC-700X Tiltable Bridge Cutting Machine
FOB Price:$28000-29000
Type:
Stone Factory MachinesStone Slab Cutting MachinesInfrared Bridge Cutting Machine
Usage:
Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
After-Sale
Lead Time:
WITHIN 30 DAYS AFTER RECEIVING THE DEPOSITS
Warranty:12 Months
Install and Guarantee:Customer pay for installation, Remote guidance installation
Maintenance:Online software upgrade, Remote troubleshooting
Supplier
Eatablished :Nov 29,1990
Main Product:
Stone Cutting Machine, Stone Polishing Machine, Stone Drilling Machine, Stone Calibrating Machine, Stone Chamfering Machine, Stone Profiling Cutting Machine|
Machinery Function Features
SQC-700X Tiltable Bridge Cutting Machine uses PLC system and Human-machine interface, combined with Ultra-high precision rotary encoder to locate and infrared device, uses inverter to control left-right feeding, adjusting the speed according to the stone material. It uses hydraulic lifting system. The key part adopt imported good-quality spare parts. The head can rotate 0-50 degree, applied in a wider range. Thus the whole machine is featured as high cutting efficiency, high cutting precision, high stability, easy-operating to suit granite and marble with high value and big size, and shaped stone products.
Technical Data
Parameters |
Unit |
SQC-700X |
Blade tilting angle |
° |
0°-50° |
Disc diameter |
4 |
700 |
Dimensions of the work table(L×W) |
4 |
3200*2000 |
Max. cutting depth |
4 |
220 |
Worktable Turn-over degree |
° |
0-85° |
Machine height |
mm |
3600 |
Max.lifting stroke |
mm |
470 |
Approximate weight without table |
Kg |
6400(Includes steel stand 7500kg) |
Main motor |
kw |
18.5 |
Machine width |
mm |
5700 |
Machine length |
mm |
6000 |
Processed Stone Photos
-
Cutting slab
Components
-
Main machine
Consumables
-
button
Customer Case
Domestic customer
China
China
