Paragon 2100/7/V/73 Evo Multi Wire Saw Machine

Name: Paragon 2100/7/V/73 Evo Multi Wire Saw Machine
Brand: Breton S.p.A.
SKU: 639
Price: 10000 USD
Availability: InStock

FOB Price:

Type: Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine

Usage: Granite, Marble, Travertine

After-Sale

Install and Guarantee:Customer pay for installation, Remote guidance installation, Third-party team installation

Maintenance:Online software upgrade, Regular guidance & maintenance, Remote troubleshooting, Field troubleshooting

Trade Terms

Delivery Details: FOB

Payment :

Supplier

Breton S.p.A.

Italy

Eatablished :Dec 31,1962

Main Product:

Stone Machines, Cutting Machine, Polising Machine, Wire Saw, Cnc Machines|

Contact supplier

Start Order

You may also like

Multi-Wire Saw Machine For Granite And Marble Blocks Sawing

Super Thin Diameter Cable Multi Wire Saw Machine For Marble Slabs Cutting

2025 High Benefit Ultra Thin Multiwire Saw Stone Block Cutting Machine

Skystone Multi Wire Saw Machine For Stone Block Cutting

TJ3520 Multi Wire Block Cutting Machine Thin Wire Saw For Stone

Product Detail
Company Profile

Overview
Components
Trade Terms
Customer Case

Machinery Function Features

Paragon multi-wire machines are proposed and manufactured with diamond-shaped wires with diameter of 5.3mm, 6.3mm or 7.3mm. Breton is at your disposal to see our Paragon machines in action, working with different diameter wires on marble. We will provide you with all information you need to make economical calculations of convenience in the use of wires of different diameter.

Technical Data

Parameters	Unit	PARAGON2100/7/V/73	PARAGON2100/7/F20/74	PARAGON2100/7/F30/55	PARAGON2100/6/V/76	PARAGON2100/6/F20/78
Max. Cutting length	mm	3750	3750	3750	3750	3750
Machine length (L)	mm	10800	10800	10800	10800	10800
Approximative Weight	Kg	50000	50000	50000	50000	50000
Max. Cutting width	mm	2095	2080	2079	2092	2102
Diamond bead diameter	mm	5.3/6.3/7.3	5.3/6.3/7.3	5.3/6.3/7.3	5.3/6.3/7.3	5.3/6.3/7.3
Main motor power	kW	- /250 (marble/granite)	- /250	- /200	315/200	315/250
Machine height (H)	mm	7900	7900	7900	7900	7900
Max. Cutting height	mm	2200	2200	2200	2200	2200
Max. Number of wires for sawing 20mm thick.	nr	73	74		76	78
Slabs nominal thickness	mm	20	20	20	20	20
Pitch groove wire driving	mm	9.7	28.5	38.5	9.3	27.3
Output number of slabs 30mm per linear mt.	nr	25.8		26	26.9
Machine width (W)	mm	6800	6800	6800	6800	6800
Output number of slabs 20mm per linear mt.	nr	34.4	35.1		36	36.6
Max. Number of wires for sawing 30mm thick.	nr	54		55	57
Wire pitch for sawing 20mm thick.	mm	29.1	28.5		27.9	27.3
Wire pitch for sawing 30mm thick.	mm	38.8		38.5	37.2	-
