Add To CompareType: Stone Factory MachinesStone Block Cutting MachinesCNC Diamond Wire Shaping Machine
FOB Price:
Warranty: 12 Months
Usage: Granite, Marble, Sandstone
Machinery Function Features:
FUEGO 4X reflects the innovative and technological spirit of Breton.
It is a machine suitable for block shaping and slab/small blocks cutting, capable of interpolating 4 axes.
It is usually equipped with a motorized block-holding trolley with brushless motor and loading platform; it enables to execute profiles such as columns, frames and shapes for funerary art and interior decoration, by interpolating the vertical cutting axis with the trolley advance horizontal axis.
Designed on the basis of the single-wire machine "FUEGO Multiaxis", it is equipped with special wire-driving drums which can be oriented adjacent to the entrance and exit of the wire from the block in order to follow the cutting direction.
It is equipped with special drives for axis positioning and with a powerful, user-friendly, CAD/CAM programming software to be installed on the customer’s computer.
Breton Fuego 4X represents the quintessential innovative and technological spirit of the company.
The machine, which can interpolate up to 4 axes, is designed for shaping and dimension sawing of large and small blocks by means of a diamond wire to create complex geometries.
Italy
Breton S.p.A.
Contact Supplier
-
Add To CompareType: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
FOB Price:
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone
Machinery Function Features:
T30 S Electronic Giant Disc Saw:
Stability of machine in operation guaranteed by a over dimensioned frame in welded steel.
On the electrical board it is installed the control panel with Touch Screen to visualize alarms, operator instructions and operational parameters for development of correct workyng cycle to be seen in real time.
Cutting unit with rack / pinion system powered for beam travel by electric gear motor that allows cutting speed selection.
Bridge translates on bearings with rack / pinion system powered by electric gear motor with inverter for perfect speeds.
Head vertical movement with self-braking motor, on prismatic guides (with guard). Accurate positioning of all axes thanks to encoder.
Main transmission through high performance belts and oil-bathed gear. Inverter provides spindle rev. changes.
Mobile control pad can be connected to water-tight electrical cabinet.
Terminal on control panel comprises display and keyboard and operator instructions, alarms and operating parameters can be viewed in real time.
Terzago
Italy
Terzago Macchine
Contact Supplier
-
Add To CompareType: Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine
FOB Price:
Warranty: 12 Months
Usage: Marble, Limestone, Onyx, Sandstone, Travertine
Machinery Function Features:
MULTIWIRE JUPITER GS220 is an open frame multiwire machine for the production of granite and marble slabs that performs blocks fast cutting through a set of diamond wires. It is available in several versions which differ for the maximum number of wires and for the diamond wire diameter (7,3 mm – 6,3 mm – 5,3 mm).
It stands out for its flexibility, reliability, state-of-the-art technical solutions and for its high production capacity.
Pedrini
Italy
Pedrini S.p.a. ad Unico Socio
Contact Supplier
-
Add To CompareType: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
FOB Price:
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Artificial Stone, Basalt, Quartzite
Machinery Function Features:
Large machine ideal for small, medium and large companies for cutting stone, marble and granite, both in manual and automatic cycle. This machine also performs complex profiles and shapes on a very large cutting surface.
Max blade size of 1600 mm (63 in) - 2000 mm (78.7 in) optional.
Machine built in cast iron and protection covers in stainless steel.
The standard machine is supplied with the following:
- fixed head for marble and granite;
- optical template scanner;
- manual rotating table (optional: programmable automatic table);
- eletronic variable speed on the disc motor;
- software POLIAX for control;
- 12" touchscreen colour display with LAN connection and USB port;
- folding door solid panel safety barriers.
GMM
Italy
Gmm S.p.A.
Contact Supplier
-
Add To CompareType: Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine
FOB Price:
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
The Two-Wires Saw Machine of Grani Roc is designed for a high slabbing production from stone blocks. The machine is mobile and has an automatic system for thickness changing. These characteristics make the machine being very versatile and time saving in loading and unloading operations as well as changing the thickness of each cut. In this machine the user can input up to 10 different measurements for the thickness of the slabs and the machine will move automatically the wires and also will adapt the movement of the trolley to obtain the desired cuts.
·The bridge structure and pillars of the machine are built in laminated steel. All surfaces of contact between the different parts are machined for guaranteeing high precision in assembly and also in the cutting process.
· All the steel elements of the structure are subjected to a surface finishing consisting of a deep cleaning and degreasing treatment, a metallization treatment and corresponding protective layers and painting. These treatments enhance the durability of the machine against
aggressive weather and working conditions.
· The main motor is direct in the main pulley, and it is controlled by an electronic frequency variator –inverter-, that permits to apply progressive linear speed to the wire and its adjustment to optimize the behaviour and performance of the tool.
· The tensioning of the wire is made pneumatic and automatically and independent for each wire, with indication of wire breakage or shortage.
· The machine has an automatic system for adjusting the distance between wires, instead of having manual devices or having to remove all the wheels manually for changing the thickness of the slabs to be cut.
· All the main pulleys –drive and tensioning– and guiding wheels are protected by rubber liners in order to get the necessary traction of the wire. Such liners can be easily changed once they are worn out.
· The machine is equipped with an automatic cooling system for the diamond wire with detection of constant water pressure. This system stops the machine in the case of lack or insufficient water flow, protecting the tool and preventing possible deterioration or damage of the equipment.
· All the up and down screws are protected with hoods against dust and water.
· The machines has an automatic greasing system that injects lubricating liquid in the critical parts of the machine ensuring their correct functioning and the long life of the spare parts.
· The control panel is situated in the lateral part of the machine and moves with it. It has all the drive and protection components and devices of all control and safety equipment of the machine. All these components are standard, allowing easy and quick maintenance and / or replacement.
· The machine has its own mobile compressor, necessary for the pneumatic system for tensioning the wire
Grani Roc
Spain
Grupo Hedisa
Contact Supplier
-
Add To CompareType: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
MAXI 3000 RX and MAXI 3500 RX are sawing machines with a jumbo disc for cutting marble and granite at the desired thickness. These machines follow the Simec philosophy of the NT2 block cutters, with 2 columns fixed to the ground and the mobile block carrying trolley, to guarantee the absence of vibration, high productivity and long diamond lifetime.
SIMEC
Italy
Simec S.p.A.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Artificial Stone, Travertine
Machinery Function Features:
The HK-0103/A Block Cutter is fully automatic with 4 columns.
It can support a block with 25 tons of weight. It cuts the block in vertical and horizontal ways. The table goes out to take the block, and then the table will come back to the center of the machine and remain stable so that the machine starts to work and move to cut the block. We insert the parameter of width of tile to be cut (example: 2 cm) and the height of the tile to be cut, then the machine works automatically.
We can also work manually with this machine.
It has a complete PLC system. -
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesSingle Arm Block Cutting Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Kamhan Industrial Limited
Pakistan
Kamhan Industrial Limited
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesVertical-Horizontal Block Cutting Machine
$45000-47000
Warranty: 12 Months
Usage: Marble, Limestone, Onyx, Sandstone
Machinery Function Features:
It is the hand on the automatic grinder automatic grindign mill and bridge on the basis of a comprehensive technical imporovemnets,learn form each other and developed a new grinding polishing equipment.This machine uses fully automatic grinder displacement,micro-computer control,grinding head movements using pneumatic pressure,high degree of automation;machine is characterized by: processing efficiency,sheet gloss and smoothness of high low labor intensity,low production costs,the low rate of broken plate,is ideal for handheld grinding machine replacement.
Mountain tigher
China
Laizhou Shanfa Stone Machinery Co.,Ltd
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
MAIN MOTOR : 20 HP, 960 RPM (Hindustan, Crompton, Siemans)
BEAM LENGTH : 14 FEET
TRAVELLING MOTOR : 2 HP DC/AC
UP / DOWN MOTOR : 2 HP
CONTROL PANEL WITH LOOM : PANEL TO MACHINE
V-RAIL LINE {10 feet x 2 nos.} : 20 FEET
FOUNDATION BOLTS : 12 NOS. {With nut & washer}
LOADING TROLLEY (7’ X 3’) : 2 NOS. { Manual}
MASTER TROLLEY (7’ X 3’) : 1 NOS. { Manual}
CUTTER GUARD : 1 NOS.
Bhagwati Machine Tools
India
Bhagwati Machine Tools
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
This frame-saw "DIAMOND FGKJ-100/800" is used in workshops and this machine allows sawing different kinds of marble blocks in plates of various thicknesses, Used for the big production of stone slab. Tools used are steel blades with sintered diamond plates.
The main motor adopts a high-efficiency energy saving motor, connect with the hydraulic coupler to make sure the energy saving. it adopts a large fly wheel o increase the running stability. PLC control system. make sure the main motor is working on constant power, the block up speed can be automatic adjusted by PLC control system to fit the different hardness. Sole design machine system and electriacal system make sure our machine will be the most high-efficiency.
All the main bearing adopts Japanese NSK brand, Sweden SKF brand make sure long service life and excellent performance.
Different size machine suitable for different size block processing request.
Frugoli
China
Fujian Frugoli Machinery Development Co.,Ltd.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
BM
Italy
BM Officine Meccaniche S.r.l.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone
Machinery Function Features:
Block Cutters T14 SM – T16 SM:
As a tradition Terzago the block cutters are built with dimensional generosity, with strong cast iron bridge for a time performance of undisputed length.
Built in the four columns frame and in the two columns frame.
For marble and granite, mono or multi discs.
Block cutter with automatic cycle for cutting marble.
Heavy duty type for transforming blocks of marble and similar stone into strips. Built in cast iron on four columns. Connecting beams and over-size bridge in cast iron.
Working speed of electrically powered blade-head unit can be regulated.
Hydraulic opening/closing of horizontal blade with dedicated line.
Transverse bridge movement is electric with rack/pinion system, running on interchangeable levels and positioning with encoder.
Vertical movement with four precision screws mounted on columns with four worm screws. Four counter-screws prevent accidental falling of bridge. One-speed step-cutting motor for rotation of screws synchronised by connecting shaft; encoder for positioning.
Main transmission by high performance tracks with oil-bathed gear box. Shaft rev. changes by pulley Motorised block carriage.
Centralised lubrication. Water-tight electrical cabinet.
Control panel with keyboard and real-time display of operator instructions, alarms and operating parameters.
Terzago
Italy
Terzago Macchine
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesCNC Diamond Wire Shaping Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Quartzite, Sandstone, Travertine
Machinery Function Features:
The MEB Profiling machine of GRANI ROC is designed for a high precision dressing of blocks and slabbing and profiling production from stone blocks. The machine is composed of a static structure and a mobile trolley. All the movements are controlled by a 2 axes CNC panel board.
· The movements of the machine are controlled by a 2 axes CNC. The data can be input directly in the CNC or by an ISO code file generated by the CAD-CAM software GraniCAD supplied with the machine. This software allows to design the pieces to be profiled, to transfer the *.dxf files to the CNC, to define the parameters of cutting in each step of the cut (speed of cutting, speed of the wire, etc.) and to simulate the path of the wire during the cut.
· Once the profiling file has been input in the machine board, the operator will have the possibility of modifying parameters such as cutting speed, wire speed with a full system of security on possible water shortage, wire broken, wire short or any kind of failure the machine may have.
· The machine has an electric system for bringing closer the small guide wheels that allows the operator to adjust the cutting width until the one desired, reducing the arch value when cutting with diamond wire and thereby increasing its speed.
· The tensioning of the wire is made pneumatic and automatically with indication of wire breakage or shortage. In this way the machine controls automatically the down movement of the machine, adapting it to the optimum working tension of the wire, avoiding possible breakages and optimizing its behaviour.
· All the main pulleys –drive and tensioning– and guiding wheels are protected by rubber liners in order to get the necessary traction of the wire. Such liners can be easily changed once they are worn out
· The machine is equipped with an automatic cooling system for the diamond wire with detection of constant water pressure. This system stops the machine in the case of lack or insufficient water flow, protecting the tool and preventing possible deterioration or damage of the equipment.
· All the up and down screws are protected with hoods against dust and water
· The machines has an automatic greasing system that injects lubricating liquid in the critical parts of the machine ensuring their correct functioning and the long life of the spare parts.
· The control panel is situated in the lateral part of the machine and moves with it. It has all the drive and protection components and devices of all control and safety equipment of the machine. All these components are standard, allowing easy and quick maintenance and / or replacement.
· The trolley is 2.300 x 2.300 mm and has a maximum capacity of 30 Ton. The rotation is manual 360º and can be blocked every 90º
Grani Roc
Spain
Grupo Hedisa
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine
Warranty: 12 Months
Usage: Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
MULTIWIRE JUPITER GS220 is an open frame multiwire machine for the production of marble slabs that performs blocks fast cutting through a set of diamond wires. It is available in several versions which differ for the maximum number of wires and for the diamond wire diameter (7,3 mm - 6,3 mm- 5,3 mm- 4,3mm).
Pedrini
Italy
Pedrini S.p.a. ad Unico Socio
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
$-7000
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
MAS-70 STONE CUTTING Machine with tools
DAP UKRAINE:9000$
Mastone
China
Xiamen Mastone Equipment Co.,Ltd
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
MKS
Turkey
MKS Marble Cutting and Polishing Machines Co.Ltd.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Onyx, Sandstone
M.A.Y. Ucler Makine
Turkey
M.A.Y. Ucler Makine
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
This frame-saw "DIAMOND FGKJ-90/800" is used in workshops and this machine allows sawing different kinds of marble blocks in plates of various thicknesses, Used for the big production of stone slab. Tools used are steel blades with sintered diamond plates.
The main motor adopts a high-efficiency energy saving motor, connect with the hydraulic coupler to make sure the energy saving. it adopts a large fly wheel o increase the running stability. PLC control system. make sure the main motor is working on constant power, the block up speed can be automatic adjusted by PLC control system to fit the different hardness. Sole design machine system and electriacal system make sure our machine will be the most high-efficiency.
All the main bearing adopts Japanese NSK brand, Sweden SKF brand make sure long service life and excellent performance.
Different size machine suitable for different size block processing request.
Frugoli
China
Fujian Frugoli Machinery Development Co.,Ltd.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Wire Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Slate, Onyx, Artificial Stone, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
The multiwire machine of BM, the KODIAK EVOLUTION, is suitable for cutting granite blocks into slabs of various thickness. It is made in different size models, in order to install from 20 up to 84 diamond wires. The machine is exclusively constructed on 4 columns, guaranteeing the best stability and cutting precision. The machine can install diamond wires of diameter 7,3 mm, 6,3 mm and 5,3 mm. The tensioning of the wires is by a BM’s patented system, which guarantee the homogeneous independent tensioning of each diamond wire. The “triangle” structure allows the diamond wire to work only on 3 touching points, reducing to the minimum the stress of the wire during the work. The bigger diameters of the rollers and wheels, reduce the inclination angle of the diamond wire, extending so the life of the wire
BM
Italy
BM Officine Meccaniche S.r.l.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesCNC Diamond Wire Shaping Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Quartzite, Sandstone, Travertine
Machinery Function Features:
The MEM Profiling machine from GRANI ROC is designed for a high precision dressing of blocks, slabbing and profiling production from stone blocks. The machine is mobile and all the movements are controlled by a CNC panel board. The friendly automation and control of all the systems of the machine along with the characteristic of being mobile, make the machine being very versatile and time saving in loading and
unloading operations as well as changing the thickness and shapes to be cut.
· The movements of the machine are controlled by a 2 axes CNC. The data can be input directly in the CNC or by an ISO code file generated by the CAD-CAM software GraniCAD supplied with the machine. This software allows to design the pieces to be profiled, to transfer the *.dxf files to the CNC, to define the parameters of cutting in each step of the cut (speed of cutting, speed of the wire, etc.) and to simulate the path of the wire during the cut.
· Once the profiling file has been input in the machine board, the operator will have the possibility of modifying parameters such as cutting speed, wire speed with a full system of security on possible water shortage, wire broken, wire short or any kind of failure the machine may have.
· The machine has an electric system for bringing closer the small guide wheels that allows the operator to adjust the cutting width until the one desired, reducing the arch value when cutting with diamond wire and thereby increasing its speed.
· The tensioning of the wire is made pneumatic and automatically with indication of wire breakage or shortage. In this way the machine controls automatically the down movement of the machine, adapting it to the optimum working tension of the wire, avoiding possible breakages and optimizing its behaviour.
· All the main pulleys –drive and tensioning– and guiding wheels are protected by rubber liners in order to get the necessary traction of the wire. Such liners can be easily changed once they are worn out
· The machine is equipped with an automatic cooling system for the diamond wire with detection of constant water pressure. This system stops the machine in the case of lack or insufficient water flow, protecting the tool and preventing possible deterioration or damage of the equipment.
· All the up and down screws are protected with hoods against dust and water
· The machines has an automatic greasing system that injects lubricating liquid in the critical parts of the machine ensuring their correct functioning and the long life of the spare parts.
· The control panel is situated in the lateral part of the machine and moves with it. It has all the drive and protection components and devices of all control and safety equipment of the machine. All these components are standard, allowing easy and quick maintenance and / or replacement.
Grani Roc
Spain
Grupo Hedisa
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
Bridge saw BS900 suited for processing sandstone, limestone, marble and granite.
Bridge Length 3.5 m
Height adjustment not
Peripheral speed can be adjusted using inverters
PLC, to set cutting width, number of cutting strips, cutting waste
MAVECO Stone Machinery BV
Netherlands
MAVECO Stone Machinery BV
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
This frame-saw "DIAMOND FGKJ-80/800" is used in workshops and this machine allows sawing different kinds of marble blocks in plates of various thicknesses, Used for the big production of stone slab. Tools used are steel blades with sintered diamond plates.
The main motor adopts a high-efficiency energy saving motor, connect with the hydraulic coupler to make sure the energy saving. it adopts a large fly wheel o increase the running stability. PLC control system. make sure the main motor is working on constant power, the block up speed can be automatic adjusted by PLC control system to fit the different hardness. Sole design machine system and electriacal system make sure our machine will be the most high-efficiency.
All the main bearing adopts Japanese NSK brand, Sweden SKF brand make sure long service life and excellent performance.
Different size machine suitable for different size block processing request.
Frugoli
China
Fujian Frugoli Machinery Development Co.,Ltd.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Granite, Basalt, Quartzite
Machinery Function Features:
Grizzly Super multiblade gang saw for granite blocks
Traditional multiblade gang saw for granite blocks cutting, using steel blades and abrasive steel shots.
The cutting speed is automatically controlled by the PLC, which determines the component percentages in the mix (slag, water, lime, granite dust) and keeps them constant
BM
Italy
BM Officine Meccaniche S.r.l.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesClosed Frame Gang Saw
Warranty: 12 Months
Usage: Granite, Marble
Machinery Function Features:
BATTERY UNIT
The battery supports have been designed to allow easy maintenance and facilitate the replacement of the roller bearings without having to break the cement foundations.The flywheel weighs 8 tons and has a diameter of 3300 mm.
STRAIGHT ARTICULATED GUIDES
The blade holder is made of steel plates joined solidly together, each of which has a section of 800x60 mm, and slides on straight articulated guides that are practi-cally maintenance free.
THE CONNECTING RODS
Equal distribution of mechanical thurst over all machine components
Advantages of two connecting rods:
• All the energy and mechanical thrust towards the blade holder is spread on two connecting rods and two cranks instead of just one.
• The two connecting rods which are attached to the extremes of the blade holder help the articulated guides to ensure that it’s movement remains perfectly rectilinear without any deviation.
BIG CUTS IN ALL SAWING COSTS!
ELECTRICAL POWER
Lower electrical power consumption thanks to:
A - Direct motor flywheel transmission by V-belts
B - Hydraulic coupling to compensate for dead times and facilitate start-ups
C - 3.300 mm diameter - 8 ton flywheel
D - Electronic emergency brake, which together with the hydraulic coupling permits fast machine stop while protecting the motor (optional)
E - “SCR” power control system (optional)
MAINTENANCE
Major points of wear eliminated thanks to:
A - Articulated rectilinear guides
B - Stainless steel parts
C - Less stress on all moving parts thanks to the 800 mm stroke and the reduced number of cycles/minute.
DIAMOND BLADE YIELD
Blade yield increased thanks to:
A - The lengthening of the blade-holder stroke to 800 mm, which facilitates the removal of the mud produced during sawing
B - The new open-duct water sprikling system, ensuring more homogeneous water distribution
C - Fewer cycles with reduced inversion of the diamond tool
BM for Breton - Diamond-bladed saw for marble with block raising
Entirely made and assembled in Italy with european parts and first-rate international components.
Italy
Breton S.p.A.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesCNC Diamond Wire Shaping Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
The SPBO profiling machine of GRANI ROC is designed for a high precision dressing of blocks and slabbing and profiling production from stone blocks.
The machine is composed of a static structure and a mobile trolley. All the movements are controlled by a 2 axes CNC panel board.
· The movements of the machine are controlled by a 2 axes CNC. The data can be input directly in the CNC or by an ISO code file generated by the CAD-CAM software GraniCAD supplied with the machine. This software allows to design the pieces to be profiled, to transfer the *.dxf files to the CNC, to define the parameters of cutting in each step of the cut (speed of cutting, speed of the wire, etc.) and to simulate the path of the wire during the cut.
· Once the profiling file has been input in the machine board, the operator will have the possibility of modifying parameters such as cutting speed, wire speed with a full system of security on possible water shortage, wire broken, wire short or any kind of failure the machine may have
· The machine has an electric system for bringing closer the small guide wheels that allows the operator to adjust the cutting width until the one desired, reducing the arch value when cutting with diamond wire and thereby increasing its speed.
· The structure of the pillars and beam is made of electrowelded and machined tubes. The trolley is composed of electrowelded tubes forming a framework protecting all sensitive parts of the trolley like rod screws, wheels, etc.
· The tensioning of the wire is made pneumatic and automatically with indication of wire breakage or shortage. In this way the machine controls automatically the down movement of the machine, adapting it to the optimum working tension of the wire, avoiding possible breakages and optimizing its behaviour.
· All the main pulleys –drive and tensioning– and guiding wheels are protected by rubber liners in order to get the necessary traction of the wire. Such liners can be easily changed once they are worn out.
· The machine is equipped with an automatic cooling system for the diamond wire with detection of constant water pressure. This system stops the machine in the case of lack or insufficient water flow, protecting the tool and preventing possible deterioration or damage of the equipment.
· All the up and down screws are protected with hoods against dust and water
· The machines has an automatic greasing system that injects lubricating liquid in the critical parts of the machine ensuring their correct functioning and the long life of the spare parts.
Grani Roc
Spain
Grupo Hedisa
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
This big machine has the same system of small one. just all the main points we make several levels bigger. Make sure the stability and safety. Cutting speed compare with the small one just a little reduce. but output is nearly double, and power consumption is nearly the same.
The main motor adopts a high-efficiency energy saving motor, connect with the hydraulic coupler to make sure the energy saving. it adopts a large fly wheel o increase the running stability. PLC control system. make sure the main motor is working on constant power, the block up speed can be automatic adjusted by PLC control system to fit the different hardness. Sole design machine system and electriacal system make sure our machine will be the most high-efficiency.
All the main bearing adopts Sweden SKF brand, make sure long service life and excellent performance.
This big machine is more suitable for the artificail stone and big producetion marble cutting.
Frugoli
China
Fujian Frugoli Machinery Development Co.,Ltd.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble
Machinery Function Features:
ORTOBRETON 4EM - RUGGED, EFFICIENT AND PRECISE
Machine featuring greater working dimensions for blades with maximum diameter of 1.700 mm.
Its rigid structure, strong construction and well-dimensioned beam limit the vibrations and assure the optimal use of diamond blades. The result is a more precise cut and a longer tool life.
RAPID AND PRECISE
The movement of both the spindle-holding carriage and the beam are in an oil bath, always precise, rapid and well protected. Once the beam has reached the correct position, it is blocked laterally on the bridges by means of a double oil-pressure device.
The two bridges move on sliding blocks with play adjustment along the guides, which are housed inside the columns, well protected by labyrinth seals. The spindle-holding carriage is moved horizontally by an electric motor controlled by an inverter.
The 550 mm ø horizontal blade spindle is mounted vertically on one side of the carriage and it can be adjusted in height by a rack and pinion assembly powered by a reducer with invertercontrolled A/C motor. The unit is equipped with a mechanism for the automatic compass movement of the blade. The rectified and dynamically balanced spindle shaft guarantees an exceptional precise rotation.
SIMPLE AND SAFE
The Ortobreton 4EM can be equipped with an automatic strip unloader.
Ortobreton 4EM is simple and responsive to controls. A user-friendly interface helps you to work better, proposing the most suitable cutting parameters and guaranteeing the continuous memorization of work data.
Warnings are shown on the monitor as well as the technical and statistical data on production and machine operation, which assist the operator in controlling and managing the work. Moreover, the monitor automatically signals the operator when preventive maintenance is required. The machine is controlled by a PLC system.
Italy
Breton S.p.A.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesCNC Diamond Wire Shaping Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Quartzite, Sandstone, Travertine
Machinery Function Features:
The PBO profiling machine of GRANI ROC is designed for a high precision dressing of blocks and slabbing and profiling production from stone blocks. The machine is composed of a static structure and a mobile trolley. All the movements are controlled by a 5 axes CNC panel board.
· The movements of the machine are controlled by a 5 axes CNC. The data can be input directly in the CNC or by an ISO code file generated by the CAD-CAM software GraniCAD supplied with the machine. This software allows to design the pieces to be profiled, to transfer the *.dxf files to the CNC, to define the parameters of cutting in each step of the cut (speed of cutting, speed of the wire, etc.) and to simulate the path of the wire during the cut.
· The machine has an electric system for bringing closer the small guide wheels that allows the operator to adjust the cutting width until the one desired, reducing the arch value when cutting with diamond wire and thereby increasing its speed
· The guiding wheels are controlled by the CNC and independent motors which allows to position the wheels in the direction of the cut, permitting a faster speed of cutting when profiling.
· The structure of the pillars and beam is made of electro welded and machined tubes. The trolley is composed of electro welded tubes forming a framework protecting all sensitive parts of the trolley: screws, wheels, etc.
· The tensioning of the wire is made pneumatic and automatically with indication of wire breakage or shortage. In this way the machine controls automatically the down movement of the machine, adapting it to the optimum working tension of the wire, avoiding possible breakages and optimizing its behaviour.
· All the main pulleys –drive and tensioning– and guiding wheels are protected by rubber liners in order to get the necessary traction of the wire. Such liners can be easily changed once they are worn out
· The machine is equipped with an automatic cooling system for the diamond wire with detection of constant water pressure. This system stops the machine in the case of lack or insufficient water flow, protecting the tool and preventing possible deterioration or damage of the equipment.
· All the up and down screws are protected with hoods against dust and water
· The machines has an automatic greasing system that injects lubricating liquid in the critical parts of the machine ensuring their correct functioning and the long life of the spare parts.
· The control panel has all the drive and protection components and devices of all control and safety equipment of the machine. All these components are standard, allowing easy and quick maintenance and / or replacement.
· The motorised 360º turntable trolley is controlled by the CNC and has a “Backlash” system that permit the production of complex shapes as balls, screws, etc.
Grani Roc
Spain
Grupo Hedisa
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
MKS
Turkey
MKS Marble Cutting and Polishing Machines Co.Ltd.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
Mini Diamond gang saw for marble is the newest patent product made by the FUJIAN FUGAOLI Machinery company. to fill the request of chinese market, professionally to cut the small size block after 3 years research. we made this model and named it vivi. the function of this machine is much better than the old type.
The new transform system and movement system make the speed increase at least 30%.
Only use 55KW & 75KW main motor. Compared with old type. it gets 30%-50% power saving.
Compared with the old type, this machine can help save blade. diamond. water. what most important is that it doesn't require square the small size block any more. Becasise one of this machine can settle all the problems of small block.
Frugoli
China
Fujian Frugoli Machinery Development Co.,Ltd.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesCNC Diamond Wire Shaping Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Quartzite, Sandstone, Travertine
Machinery Function Features:
The PBO profiling machine of GRANI ROC is designed for a high precision dressing of blocks and slabbing and profiling production from stone blocks. The machine is composed of a static structure and a mobile trolley. All the movements are controlled by a 5 axes CNC panel board.
·The movements of the machine are controlled by a 6 axes CNC. The data can be input directly in the CNC or by an ISO code file generated by the CAD-CAM software GraniCAD supplied with the machine. This software allows to design the pieces to be profiled, to transfer the *.dxf files to the CNC, to define the parameters of cutting in each step of the cut (speed of cutting, speed of the wire, etc.) and to simulate the path of the wire during the cut.
· The machine has an electric system for bringing closer the small guide wheels that allows the operator to adjust the cutting width until the one desired, reducing the arch value when cutting with diamond wire and thereby increasing its speed
· The guiding wheels are controlled by the CNC and independent motors which allows to position the wheels in the direction of the cut, permitting a faster speed of cutting when profiling.
· The structure of the pillars and beam is made of electro welded and machined tubes. The trolley is composed of electro welded tubes forming a framework protecting all sensitive parts of the trolley: screws, wheels, etc.
· The tensioning of the wire is made pneumatic and automatically with indication of wire breakage or shortage. In this way the machine controls automatically the down movement of the machine, adapting it to the optimum working tension of the wire, avoiding possible breakages and optimizing its behaviour.
· All the main pulleys –drive and tensioning– and guiding wheels are protected by rubber liners in order to get the necessary traction of the wire. Such liners can be easily changed once they are worn out
· The machine is equipped with an automatic cooling system for the diamond wire with detection of constant water pressure. This system stops the machine in the case of lack or insufficient water flow, protecting the tool and preventing possible deterioration or damage of the equipment.
· All the up and down screws are protected with hoods against dust and water
· The machines has an automatic greasing system that injects lubricating liquid in the critical parts of the machine ensuring their correct functioning and the long life of the spare parts.
· The control panel has all the drive and protection components and devices of all control and safety equipment of the machine. All these components are standard, allowing easy and quick maintenance and / or replacement.
· The motorised 360º turntable trolley is controlled by the CNC and has a “Backlash” system that permit the roduction of complex shapes as balls, screws, etc.
Grani Roc
Spain
Grupo Hedisa
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesSingle Wire Block Squaring Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
Ref.: 98
Twix Roller for chipping the blocks with the diamond wire. The machine has two adjustable mobile parts to enable cutting the block into different sizes in one go. It can be programmed to cut several measurements in the same block or in various sequenced rows of blocks. Data management and storage.
Fravizel
Portugal
Fravizel - Equipamentos Metalomecanicos, S.A.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
Circular saw for sawing square blocks out of sand stone, lime stone, marble en granite. With this machine you are able to produce automatically without operator, this way you can produce very efficient.
Maveco has got two types of the Apollo, which have a different blade diameter and saw depth.
Apollo 4
Blade diameter 725 1000 1200 mm
Saw depth 260 365 440 mm
Apollo 6
Blade diameter 2000 2500 2700 3000 3500 mm
Saw depth 800 1050 1150 1300 1550 mm
Both:
Saw reach 3.5 x 3.50 m up to 20 x 3.5 m
With stationary bridge and moveable saw car or Moveable bridge over rails
Saw car 3000 x 1500 mm
25 ton load capacity
MAVECO Stone Machinery BV
Netherlands
MAVECO Stone Machinery BV
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Saw Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
Block cutter for Marble or Granite
Extremly famous for strenght, relaiability, long time duration
Terzago
Italy
Terzago Macchine
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesSingle Wire Block Squaring Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Quartzite, Sandstone, Travertine
Machinery Function Features:
Ref.: 99
Monowire Roller has the function of trimming blocks with diamond wire and cutting slabs of variable thickness. Programmable to cut several measures in the same block or in several blocks in a row placed in line.
Data management and memorization.
Fravizel
Portugal
Fravizel - Equipamentos Metalomecanicos, S.A.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesSingle Wire Block Squaring Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
DF 2000-2500-3000-3500 Single wire saw for dressing blocks and cutting slabs
TOP INVERTER OR FIXED WIRE SPEED
Single wire saw for dressing blocks and cutting slabs. Has two main flywheels of large diameter (250 or 200 cm as to the maximum cutting height needed) to maximise the cutting speed and the life of the damond wire. The wire tensioning system is hydraulic.
Stiff metallic structure can carry flywheels of diameter either 2000 or 2500 mm.
Electronic drop speed control. The machine uses only two large flywheels (diameter 2000 or 2500 mm) thus reducing wire fatigue. The switchboard is separate from the machine, and includes a number of safety devices with segnalations of eventual anomalies of the cut. Diamond wire tensioning uses one of the two flywheels thanks to an hydraulic piston.
The TOP version has an inverter to adapt the wire speed to the type of stone to be cut. The basic machine has fixed wire speed, set for the material to cut
Pellegrini
Italy
Pellegrini Meccanica SpA
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
Mini Diamond gang saw for marble is the newest patent product made by the FUJIAN FUGAOLI Machinery company. to fill the request of chinese market, professionally to cut the small size block after 3 years research. we made this model and named it vivi. the function of this machine is much better than the old type.
The new transform system and movement system make the speed increase at least 30%.
Only use 55KW & 75KW main motor. Compared with old type. it gets 30%-50% power saving.
Compared with the old type, this machine can help save blade. diamond. water. what most important is that it doesn't require square the small size block any more. Becasise one of this machine can settle all the problems of small block.
Frugoli
China
Fujian Frugoli Machinery Development Co.,Ltd.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMonolama Cutting Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
Monolame Diamond wire squaring machine for sand and lime stone, granite and marble.
Number of wires 1
Cutting depth 2100 mm
Sawing reach 4000 x 2300 mm
Hydraulic unit motor
Number of blade strokes 160 /min
Stationary bridge
Saw table (car) 2300 x 2300 x 670 mm / 30 Tons
MAVECO Stone Machinery BV
Netherlands
MAVECO Stone Machinery BV
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesSingle Wire Block Squaring Machine
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine
Machinery Function Features:
Single wire saw for dressing blocks and cutting slabs; similar to the above wire saw but fitted with a fully electronic control and tensioning system and with a PLC for automatic slabbing.
Metallic structure is similar to DF TOP but the system is controlled by a Telemecanique PLC for full automatic control of all machine functions during operation. The switchboard is separate from the machine, and includes a number of safety devices to signal any cutting anomalies. Electronic drop speed control based on the adjustable maximum wire bow during cutting. Automatic slabbing is provided, and inclined and horizontal cutting can be done with the addition of two pairs of wire guide-wheels. Diamond wire tensioning uses one of the two flywheels with an electric actuator for positioning
Pellegrini
Italy
Pellegrini Meccanica SpA
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesClosed Frame Gang Saw
Warranty: 12 Months
Usage: Marble, Limestone, Sandstone
Italy
Marmo Macchine Corporation S.R.L
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw
Warranty: 12 Months
Usage: Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
GANGSAW MACHINE
MADE IN TURKEY
80 lamas
110 kW
Turkey
Kimmco Koray International Marble & Machinery Co.
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesGiant Disc Bridge Saw Machine
$23000-28000
Warranty: 12 Months
Usage: Granite, Marble, Limestone, Basalt, Quartzite
Machinery Function Features:
1,Controlled by ultra-high precision rotary encoder,high precision screw nut drive,fragmented accurately.
2,The left and right walker is controlled by frequency converter,can be adjusted according to the material of the stone,to ensure cut the slab high efficiency and high quality.
3,Independent research and development of hydraulic system,four-guider column structure,guider column is chrome-plated,plus sealing guide sleeve,the sleeve is designed with a multi-layer seal,waterproof,dust proof,oil leakage proof,with a small gap.The whole machine is beautiful,improve service life.
4,Humanized man-machine operation interface,easy to operate,easy to operate,fragmented accurately,flatness,high efficiency,especially for high-value granite and marble.
China
Shuinan Stone Machinery Co.,Ltd
Contact Supplier
-
Add To Compare
Type: Stone Factory MachinesStone Block Cutting MachinesMulti Blade Gang Saw Cutting Centre–Vertical
Warranty: 12 Months
Usage: Marble, Limestone, Sandstone, Travertine
Machinery Function Features:
The STANDISH MULTI-BLADE SAW is designed for cutting slabs of stone to various widths to use
for veneer, lintels, treads, sills, etc. This machine greatly increases production because of its ability
to make multiple cuts at one time as opposed to using a single-blade circular saw. One of our
multi-blade saws currently in use has 25 blades making cuts 2” apart in one pass.
The STANDISH MULTI-BLADE SAW features:
• 40” or 48” Diameter Diamond Blades
• Normal Blade Tip Speed—10,000 Ft. per minute
• Furnished with blade spacer kit according to customer’s job needs
• Throat Capacity of 66” Wide x 18” High (48” Blades), 14” high (40” Blades)
• Furnished with equipment required to install and remove blades
• Blade arbor is quickly interchangeable for changing different blade spacing.
• Normally mounted over a wood slat conveyor.
• Requires power supply for 400 H.P.
United States
Standish Steel, Inc.
Contact Supplier
Have a Question? Ask our expert
Ask now
