F-Top Slab Polisher - Polishing Line Machine

Name: F-Top Slab Polisher - Polishing Line Machine
Brand: Sassomeccanica S.p.A.
SKU: 4079
Price: 10000 USD
Availability: InStock

FOB Price:

Type: Stone Factory MachinesStone Surface Processing Machines Slab Polishing Line Machine

Usage: Granite, Marble, Limestone, Onyx, Basalt, Quartzite, Sandstone, Travertine

After-Sale

Warranty:12 Months

Install and Guarantee:Customer pay for installation, Remote guidance installation, Third-party team installation

Maintenance:Remote troubleshooting, Field troubleshooting

Supplier

Sassomeccanica S.p.A.

Sassomeccanica

Italy level 8YR

Eatablished :Dec 31,1974

Main Product:

Stone Machinery, Edge Polishers , Saw Jet, Slab Polishers, Bridge Saws|

Contact supplier

Start Order

You may also like

HLMJD-12C/20C Fully Automatic Stone Slab Polishing Line Machine

Granite Auto Polishing Line Machine For 1.3M Width

SPG/SPM Plus Automatic Marble And Granite Polishing Line

Automatic Polishing Machine (ZDMJ-16S)

ANYTH-V Stone Slab CNC Polishing Line Machine

Product Detail
Company Profile

Overview

Machinery Function Features

Strong and solidly-built. A project of high engineering. Over 40 years of innovation made F-TOP a slab polisher of excellence. Ergonomic and advanced design. High performance and safety. For a long-lasting performance at maximum efficiency. 1 Hot dip galvanisation Ensures the benches will last through time 2 Versatility Versatile and high performing, the machine comes with a slab reading system that automates the polishing process. The polishing beam and spindles ensure high performance thanks to a wide variation of oscillation speed 3 Compactness Thanks to its one-piece structure, the machine takes up little room, and loading and unloading the slabs on the tilting bench is very easy

Technical Data

Parameters	Unit	06	08	10	12	14	16	2-8	3-10	4-12
Number of polishing heads/honing units	nr	6	8	10	12	14	16	8	10	12
Conveyor system forward speed	mm/min	0-3 (min-max)	0-3 (min-max)	0-3 (min-max)	0-3 (min-max)	0-3 (min-max)	0-3 (min-max)	0-3 (min-max)	0-3 (min-max)	0-3 (min-max)
Number of Dressing spindles	nr							2	3	4
Slabs max. processable width	mm	2100	2100	2100	2100	2100	2100	2100	2100	2100
Cooling water requirement	L/min	150	200	250	300	350	400	250	325	400
Total installed electrical power	kw	49	64	80	96	111	127	89	117	143
Approx. Weight	Kg	10000	11000	12000	13000	14000	15000	14000	16000	18000
Machine overall width	mm	2900	2900	2900	2900	2900	2900	2900	2900	2900
Belt advancement motor power	kw	2,2	2,2	2,2	3	3	3	3	3	3
Machine overall height	mm	2100	2100	2100	2100	2100	2100	2100	2100	2100
Slab polishing speed	m/min	24	24	24	24	24	24	24	24	24
Slabs min. processable thickness	mm	20	20	20	20	20	20	20	20	20
Calibrating plate diameter	mm							500	500	500
Polishing heads/honing units motor power	kw	7,5	7,5	7,5	7,5	7,5	7,5	7,5	7,5	7,5
Power of each dressing unit	kw							11	11	11
Machine overall length	mm	5920	6880	7840	8800	9760	10920	8690	10190	11690
Number of abrasives for each plate	nr	6	6	6	6	6	6	6	6	6
Diameter of abrasive-holding plates	mm	440	440	440	440	440	440	440	440	440
Slabs max. processable thickness	mm	100	100	100	100	100	100	100	100	100
