Stone Block Cutting Machines

DAP UKRAINE/MOLDOVA:53000$
Multi Wire Saw Machine TSY-Mws32u With Tools

The single blade machine is perfectly suitable for squaring marble blocks or cut big thickness slabs, installing one diamond blade. The machine is supplied with a fixed trolley for the blocks, in order to cut big thickness slabs; otherwise the machine is supplied with a rotating bench trolley, in order to square the marble blocks.

The operation of the machine is by a combined hydraulic and mechanical movements, which allows the best tensioning and movement of the blade, in order to raise the speed of cut and guarantee the best precision. On the BM Super model, the diamond blade has a linear stroke of 420 mm, on the BM Super 800 the diamond blade has a linear stroke of 800 mm.

They install the same motor, so with the same electrical consumption, the 800 mm model guarantee a higher cutting speed (downfeed) and so a bigger production.

800 mm STROKE

For greater production and lower consumption of diamond segments. It is ideal for defective and abrasive materials.Sprinkling system

The newly concivied water sprinkler ensures better distribution of the water over the sawing area.

Cooling system.

A new closed circuit cooling system using non recycled water to increase the life of the pistons and gaskets.

Automatic cutting programmer displayed on touchscreen, controlled by PLC.

Reasons for choosing BM SUPER over a monofil for sawing marble:

•Minor sawing costs as diamond blades are cheaper than diamond wires.

• Higher output – in square metres – with the diamond blade than with the diamond wire.

• Greater cutting precision.

• Optimal sawing speed to quality ratio.

• Less waste of material when squaring blocks.

• An extra 6 mm for every cut because diamond blades are thinner.

• Smaller investment costs of the machine.

• Inferior sawing time on blocks with small dimensions.

"ORIGINAL" NEW & SECOND-HAND/RECONDITIONED BM MACHINES:
MARBLE SINGLE BLADE: - BM SUPER/420 - BM SUPER/800
MARBLE MULTI BLADES:
OPEN FRAME STRUCTURE DIAMOND BM 10-15 STROKE 500 - DIAMOND BM 30-40-50 STROKE 600
CLOSED FRAME STRUCTURE - DIAMOND BM 80-100 STROKE 800- DIAMOND BM 80-100 STROKE 1000
MARBLE STRIPS 100 BLADES: - MAXFIL/800
GRANITE SINGLE WIRE: - MONOFIL BM 2300 - MONOFIL BM 1000
GRANITE MULTI WIRE 2 COLUMNS: - KODIAK EVOLUTION 5->15
GRANITE MULTI WIRE 4 COLUMNS: - KODIAK EVOLUTION 20 UP TO 84 WIRES
GRANITE MULTI BLADES: - GRIZZLY SUPER

Paragon multi-wire machines are proposed and manufactured with diamond-shaped wires with diameter of 5.3mm, 6.3mm or 7.3mm.



Breton is at your disposal to see our Paragon machines in action, working with different diameter wires on marble.



We will provide you with all information you need to make economical calculations of convenience in the use of wires of different diameter.

For sale, Remanufactured (2021) Gang-saw multi-blade with 40 blades (standard) to 60 blades for cutting blocks of marble, travertine or tufa.
Every piece of the frame: pillars, cross members, crossbars, pulleys, etc., was disassembled and cleaned to pure metal by sandblasting. Next, the pieces were taken to a machine-shop and rebuilt, one by one, putting in new bearings, bushings, screws, etc. Then they were painted with epoxy anti-rust primer and acrylic paints.
Both the main machine and the block transport trolley was deliberately left unpainted, which is also rebuilt and fully functional (wheels, motor, etc.). It is spotlessly clean without rotting, cement residues, marble mud, etc. and the buyer can either use it directly or cover it with cement according to his needs.
The base of the main electric motor (78KW) is newly manufactured.
The main electric motor (78KW) is in best condition.
The brake-system of the trolley is also made new. You may see it in the attached photos and videos.
All the above can be seen in the attached photos and videos, because there are no remains of marble mud, broken pieces from being cemented into its cemented-basements, and the whole machine is spotless.
The price of 35,000 Euros does not include the electric control panel. A new electric control panel can be made for an additional 3,000 Euro.
The price does not include the cost of unloading and loading. In case that we undertake the responsibility of dismantling and loading into a container, the total cost is 2500 Euro.
If you do it yourself, then, you will pay only the crane which will be a very low amount.
35,000 Euros includes everything that can be seen in both the photos and the description.
The crate is located at our factory in the village of Katuntsi in Bulgaria, 10 kilometers from Greek-Bulgarian boarders..
Any question will be replied, immediately.
Best regards
Mr Dimitrios Papaevagelou
Dr Geologist Engineer
Headquarters: Serres, Greece
Factory: Katuntsi, Bulgaria

The machine GR 80 TAR is the perfect image of strength, power and control.
STRENGTH: Structure especially designed to resist high speed cutting. It has two large connecting rods and the most suitable forgings.
POWER: Its 132 Kw engine cuts all kind of material, soft or hard.
CONTROL: Automated system that controls the cutting conditions, regulating the sinking speed within the consumption of the main engine.
Besides its huge capacity, the sinking speed makes the gang saw GR 80 TAR the perfect choice for a clean and safe work.
Its cooling system by water combined with the sinking speed reduce the consumption of diamond and the risk of breaking precious material.
GR 80 TAR, designed with high technology can cut marble and granite blocks at the same time, giving the marble factories an excellent product to cover all the different stages of Stone processing.

NOTES Automatic wiresaw with 2 programmable axes, programming through Cad/cam software

The frame is provided with two carriages for loading and cutting of the blocks and of a transporter on rails for moving the carriage once released from the frame at the end sawing.

Cutting systems TBV/1300-1600 30 G
The machine allows to produce strips from blocks of granite. Its supporting structure is made of electro-welded normalized steel to guarantee the vibrations absorption. The main beam is made of electro-welded normalized steel, stiffened to tolerate high pressure load. The structures are painted with a special anticorrosive treatment and are grinded for the perfect alignment of the movement parts. The trolley translation on beam is through lateral containment wheels in oil bath with low coefficient of friction. The remaining movement parts are on grinded precision guides. All the movement parts are operated by PLC and graphic terminal installed on the panel. The disc fall on the columns is through self-bearing screws device. The machine is supplied with the horizontal disc fixed on the trolley carrying discs. The switch board is made of sheet steel, thickness 15/10 mm, painted with RAL 7032 paint, IP55 protection level, equipped with double programme of cut. The supplying unit is composed by a magnetothermic switch with shutter locking to avoid the opening of the switch board with tension.
Fittings:
- spacer flanges for various thickness of cut
(one set is included in the supply)
- stock shaft carrying discs

Superior C4000A - Diamond wire machine
Diamond wire machine is a cut system designed to obtain marble, granite and stone slabs of different thicknesses perfectly alike.
The "Superior" line has been designed specifically to square blocks, cut shims and slabs or also to cut shapeless stones or salvages.
The characteristic of base it is represented by precision of the cut and by a dimensioning of the structure particularly hardy.

SJS 220 gantry cutting machine
Cutting block
Gantry cutting machine unit (double-seat) SJS 220 with vertical movement of the upper beam
Suitable for cutting granite and marble.
Management strongly manual and automatic mode.

Columns casting with guides you exchanged again of Steel SAE 1045
Bipartite projection φ2900
Long arm without knuckle adjustment
Inferior picture with chapao of 125mm x 600mm x 3225mm
Tubular rectilinear shower
Automatic Dosador of granalha
Muzzle stops up to 80 plates
Internal measure of the sewing press: 2,8 m largura x 3,95 m length
Weight of 44t approached
It harnesses total 76 cv
Panel of digital command for all the sewing press
Door track block
Bomb 120 (With Pulley) Engine 20 cv
New features (May 2006)
Main battery special extreme Steel
Excentrico special extreme Steel
Knuckle special extreme Steel
Wrist special extreme Steel

Capacity of cut
Block: width 2,53 m x length 3,05 m x heigth 2,10 m
Plate 1,3cm = 109 you plate
Plate 2 cm = 80 you plate
Plate 3 cm = 60 you plate

Robust and simple bridge cutter. Different options depending on the number of discs needed.

From 1 to 6 discs, Diameters 1600-2200 mm.

Digafer S.A.

Pol. Ind. Las Gándaras s/n, Ap Postal 164 – 36400 Porriño Pontevedra, Spain

Phone: +34 986 337 969 | Fax: 986 337 926

[email protected]

The multiwire SW is definitely innovative both in appearance and performance. It is a machine with a two-column structure made using top-class solutions and components in order to provide the highest reliability standards. The multiwire SW, with identical technical solutions and supporting structure, are available with different cutting widths as to meet the customer?€?s specific needs. Besides, when purchasing the machine, it can be configured to operate with three different diameters of wires enabling a variety of possible versions.
Granite, Marble, Block, Blocks, Multiwire, 5.3

Multiple saw PW5 TK1600 to machine stone (cutting transversely to walls, cart running with a block)
Maximum 5 discs separated with distance rings can be mounted.

Cutting centres and Block cutters
Block cutters for granite and marble
NT2 32S - NT2 50S - NT2 60S
Block cutters with double bridge for simultaneous and independent horizontal and vertical cutting. The machine versions available are with 32, 50 or 60 disks, for granite and marble, same general features. All machines can be equipped with automatic unloaders, aerial front or side type.

GTM 1600 - Block cutters for Marble
This machine is designed for cutting marble blocks into strips by means of a series of one to five vertical discs and one horizontal disc.
Machine specifications:
The machine is composed of two vertical columns joined by a very sturdy support beam so as to ensure the stability of the structure.
The movement of the bridge up and down the columns is by means of two carriages with bronze sliders which run along two ground and rectified channels. These channels are made in the columns and are covered by a special wear-resistant tempered steel belt which guarantees the machine’s accuracy over time.
The main bridge which runs along the columns is made up of a special steel beam with a very thick closed section which houses special roller runners. These work in an oil bath and have airtight seals. Cutting accuracy is guaranteed thanks to the way in which the runners are connected to the columns.
Both cutting and the movement of the block carriage are programmed and controlled by a PLC which ensures maximum accuracy throughout the machine run.
The block carriage is a sturdy steel structure which moves on special double steel wheels assembled on roller bearings.
The wheels are flat/prismatic for their accurate movement under the machine along flat/prismatic rails and bars for their movement outside the cutting area.
The carriage is powered by a self-braking motor with a gear reduction unit which caters for the micrometric movements in the cutting area and other movements for the loading and unloading of the blocks.
The accuracy of the carriage movements is guaranteed by a special encoder which is an integral part of the rails and is connected to the mobile carriage by means of a steel cable. The dimensions of the block carriage are 330 cm (length of the block) by 230 cm (width of the block).

DECAWIRE from Pellegrini
Pellegrini's DECAWIRE: 10 wires for thin and thick slabs!
Easy & fast thickness adjustment
10 slabs from 2-10cm (3/4˝ to 4˝)
Big wheels offer lower stress for longer life of diamond wire
Low energy & low water consumption

TBV 1200 - 10 MG / TBV 1600 - 4 MG
This model is extremely versatile.Its double control program it can saw marble in a single pass or saw granite in multiple passes with one or more disks depending on production requirements.

Disks lowering, whether in single or multiple passes,takes place on four columns with self-lubricating screws.The structural features of the machine are identical to those of the version TBV 1200 – M and TBV 1600 - M.

TRIMWIRE harmonizes the advantages of a stationary machine with a mobile quarry machine.

Very unique, it is composed of a single wire structure installed on a tracks vehicle equipped with a diesel engine that makes the system independent from any external energy source.

The machine is designed to be easily configured for transport from quarry to quarry on trailer.

Once the machine has been stabilized on the side of the block by 4 hydraulic stabilizers, the cutting arch is brought to the desired height and opened to align the wire to the face of the block to be cut.

The cut is performed vertically thanks to the movement of the arch structure along the column.

The wire is driven by a motor flywheel 1000 mm diameter and guided by 600 mm diameter wheels.

The entire cutting structure can also move along the rails (4 meters) placed on the top of the vehicle to allow the realization of different thicknesses with a single positioning of the vehicle.

All the drives are hydraulic and the main controls are operated by radio control device.

Total weight:7 tons

Translation speed on tracks low/fast:1,2 km/h - 2,3 km/h

Superable slope in autonomous movement:

30% (17°), in velocità lenta / in low speed

Angle of inclination limit of lateral tilting with machine in autonomous movement:35% (20°)

Diamond wire speed:up to 40 mt/sec, adjustable

Maximum sizes of the workable block:Width 3,8 mt; Height 2,5 mt

Maximum distance of the second parallel cut:max 4 mt

Diesel motor: 18,5 kW

Lenght of the diamond wire: 16,4 mt

Diameter of the diamond wire: 8,3 mm or less

The first saws I designed were engine-driven hydraulic saws. They are still operating today.
Now the saws we design are electric/hydraulic with sophisticated electronic controls. We can custom design saws to meet your needs, from a standard 6-foot by 12-foot single wire saw to a multi-wire high-production saw for large-scale stone cutting. Please contact us to discuss your specific needs. Available designs include portable saws, large-scale saws, multi-wire saws and the "Super Mini." For more information, please contact Art Horvath directly

EEW Type Machine to cut stone.
(Economy type)
This machine cuts stone with accuracy.
Economy model.
Low sound cutting.
about 1.5 square meter (16 squre feet) per hour to cut gray granite.

Marble Gang Saw Machine Marble gang saw is a gang saw with parallel-transport diamond blades, block jacking-up mocing, and with a closed structure frame. It is suitable for cutting marble slabs, and suitable for mass production.

Maximum block dimensions (LxHxW): 3200x2000x2000 mm
Maximum no. of blades: 80~100 pcs
Maximum width of the blade pack: 2000 mm
Strokes per minute: 90 n/min
Length of stroke: 700 mm
Main motor power: 110Kw
Max. speed of slow down-feed: 620 mm/h
Rapid down-feed speed: 360 mm/min
Overall dimensions (WxLxH): 450x1330x550 cm
Water requirements: 800 L/min
Machine mass (approx): 50 Ton
Average level of equivalent sound pressure: 88 dbA

Automatic Vertical Block/Slab Cutting Machine.
Single Blade dia 1.35, 1.65, 1.8, 2.0, 2.3, 2.5, 2.7, 3.0 meter in Water Base.
Single Blade dia 2.5, 3.0, 3.5 meter in Kerosene base.

New concept block dressing machine which can cut one side in 1 hour time of full size blocks suitable for gang saw or multi wire machine.

This machine, fitted with diamond blade and high-speed cutting technology, is suitable for cutting marble and granite. It is suitable for cutting granite or marble slabs over 10mm in thickness.

Technical Specification
2.3 Mtr. (12 blades / 9 blades set)
• Beam Length 7 mtr. (23')
• Blade Cross Movement 4 mtr. (13' - 1")
• Blade Vertical Movement 1.44 mtr. (4' - 9")
• Blade Motor Power 75.0 hp / 1440 rpm
• Bridge Motor Power 2.0 hp / 1440 rpm
• Cross Travl. Motor Power (D.C.) 3.0 hp /1440 rpm
• Maximum Allowable blade Dia 2.3 mtr.
• Blade Spindel Housing By heavy duty helical gear box .
• Blade Thickness 5.5 mm / 6.5 mm / 4.5 mm
• Segment Thickness 7.2 mm
• Max. Producation Capacity 40,000 to 50,000 per month
• Flenge Dia 290 mm
• Trolly size 9' x 5'
• Max. Block size 2000 mm (W) x 1500 mm (H) x 3500 mm (L)
• Gross Weight of Machine approx 20 ton
• Water Requirment 3 Hp Pump
• Blade Up - down movment By 2 nos. hydroulic cylinders
• Operating system ""PLC" Control Panel
• Space Require for one machine 40' x 20'
• Space Require for two machine 40' x 40'
• Machine Max Hight 25'
• Panel Plc controled panel (auto and manual)

1. Patented operation system,easy to operate, train in 1~2days, no need to learn G code;
2. High cutting accuracy & Fast cutting speed;
3.Heavy duty structure,robust design, longer lifetime;
4.Remote service system,one-click automatic upgrade;
5.Turning cutting system is controlled by frequency convertorand will automatically identify,slow down the speed,reducethe loss of stone and tools;

The FTM 80/800 range of diamond gang saw is the fruit of the application of tema frugoli 's latest designs and technology to marble cutting machinery. The ftm 80/1000 is the first gang saw in the world to use a longer stroke when cutting the marble blocks. The longer stroke offers an unprecedented output and ensures total safety through the processing steps. Through a careful development of the machinery and closed manufacture and good cooperation with the best manufacturers of diamond blades, tema frugoli has produced a machine which guarantees a top rank performance on every kind of material, perfect reliability of its structural components, and a long lifespan.

MARBLE/GRANITE BLOCKS SINGLE SAW

MULTI-WIRE SAW MACHINE

MULTI-WIRE SAW MACHINE

Gangsaw Machine

HQKJS -2000 diamond wire saw stone cutting machine is a good choice for irregular stone processing. Easy to operate, it can cut many special shape.
HQKJS - 3000 Diamond wire saw stone profiling cutting machine . Four-Axis linkage, which can process the circular stone slab, roman column, numeral, letter, Chinese characters and other designed shapes.
1. It has heavy load bearing structure, four orbits on each upright column, adjusted the balance by the rollers, with less friction and higher precision.
2. The left and right frame achieve synchronized lifting by steering equipment on the upper frame. The lifting accuracy increased by the conbine of lead screw and double nuts.
3. Cantilever part, firstly the lead screw and pole adjust the distance of guide wheel,guide wheel is controlled by CNC. Secondly in order to make the diamond wire rope cutting direction coincidence, reducer control the guide wheel rotating angle.
4. Worktable is running by lead screw and railway.
5. There has automatic alarm if wire broken.
6. Aluminum wheel diameter is 1600mm.One fly wheel slide through sheave, oil pump control rope tension.

1) Equipped with CNC system, which makes the man-machine interface easy and flexible.
2) Flywheels tension has a stable, constant stretch mode to enhance cutting accuracy.
3) Cutting speed is adjustable according to different requirements.
4) High efficiency, the slates it processed are of exact size, and the margin is flattened and sleek.

MULTIWIRE N6860/60 TECHNICAL SHEET
The new Diamond wire cutting machine NDF 6870/60 is a multi-wire machine designed to produce boards and plates of varying thickness from the large blocks of marble and natural stone. This new unit represents the most modern technology in what refers to the primary sawing of the stone blocks, becoming the alternative to the traditionally used sawing methods, since it improves the production capacity quantitatively, efficiently taking advantage of the energy resources needed to the production of materials and significantly reducing the production costs of the cutting phase.

The multiple diamond wire cutter is a machine that stands out for its efficiency and high productivity, designed to obtain high yields, which is characterized by its great robustness, thanks to its particular design that forms a compact, balanced and balanced set where all movements are concentrated, and its proven reliability and that of the elements that compose it, being all designed to withstand the toughest working conditions.

The main structure of the machine is basically composed of two sturdy columns formed by two steel-welded steel structures, connected between them by an upper crossbar. On both columns the structure of the main frame that joins the two trolleycarriages is mounted, which move vertically supported on both columns on linear guides with linear roller recirculation skates and actuated by a pair of spindles rolled with recirculating nuts balls, synchronized and operated by two motor-reducers with independent servo motors for the ascent / descent of the threads with a smooth and precise movement, located in the upper part of both columns, the entire guide assembly is perfectly protected by PVC bellows . The servomotors are synchronized by software in the vertical movements that ensure smooth cutting, low consumption and maximum precision and avoid the slacks and problems of the central motorization with transmission and forwarding.

The Ø1800 drive drum is formed by a single multi-channel pulley with grooves and connected to the main motor by a pulley and timing belt transmission. The threads are manually positioned according to the desired thickness supported by one side of the machine on the drive drum, and in turn are tensioned from the opposite end by autonomous pulleys. The diamond wires are also guided by two multichannel drums that help to significantly reduce the arrow produced by them. From the opposite end to the driving drum, the diamond wires are supported by the set of idle pulleys, designed with a particular pivoting extraction system, which allows reducing maintenance times significantly.

Once the wires are located, these are adjusted with the active tensioning device that acts individually on each of the tensioning pulleys, independently ensuring that each of the threads has the same tension regardless of the minimum differences in length between each of the threads that are installed in the machine. The tensioning system manages to increase the useful life of the wires and therefore the profitability of the machine

The whole machine is characterized by the robustness and reliability of the elements that compose, being all designed to withstand the toughest working conditions, and in this aspect it is precisely where we can provide all the experience accumulated over the years we have been designing and manufacturing machinery for this sector.
Notable features
Reduced and optimized energy consumption.
Mechanical robustness and absence of vibrations.
Active and independent tensioning system, which increases the useful life of the threads, increasing profitability and ensuring optimum surface finishes.
Innovative pulley design, with pivoting extraction system that reduces maintenance times.
Full range of cutting thicknesses, thanks to its particular design of pulley packages and combination of grooves, without penalizing the life of the diamond wire.
Excellent precision and flatness of cut, through its particular system of guidance by linear skates and its rigid bearing structure.
Easy and convenient access to the inside of the machine, thus facilitating the work of changing threads and their maintenance.
Helical spindles with large diameter balls in vertical movement for smooth or precise movement.
Servomotors synchronized by software in vertical movements that ensure smooth cutting, low power consumption, maximum precision and avoid gaps and problems of central motorization with transmission and forwarding.
Up to 60 wires with various possibilities for the combination of cutting thicknesses.

Strong points
The multiple diamond wire cutter is a multi-wire cutter designed to produce slabs, boards and slabs of varying thickness from the large blocks of marble and natural stone. Traditionally in the factories of transformation of the granite, the cut of blocks is being made of the size of the same with looms when the blocks are of big dimensions, or with bridge cutters of big diamond discs in the workshops of stonework when cutting semiblocks.
The biggest aspect to note is that the multi-wire cutter, for an equivalent capacity, the effective energy consumption, is lower compared to any of the methods used. This translates into significant energy savings both in the implementation, as in production costs.
This difference in the equivalent energy saving is mainly due to the difference in sawing technology, the multi-wire cutter only uses up to 60 loops of diamond wire and water during this process by cutting continuously. These diamond wires are basically formed by a steel cable covered by diamond rings along the cable, the cutting effect on the stone block to obtain the slabs and boards is produced by the effect of the continuous drag movement of the wires at a linear speed of about 38 meters / sc. combined with the rotation of the rings, producing a very high cutting power, differentiated effect with respect to the large traditional looms where the cutting process can be defined as the effect of a reciprocating saw, formed by a frame that houses about 100-130 steel strips in contact with the stone blocks at the same time moving c incombination with the rain of abrasive mixture of water, steel shot and lime, which produces the same amount of incisions in the stone block that amount of strapping
In summary, the coefficient resulting from the equivalent energy consumption in Kw / m2 of a multi-wire cutter compared to the loom is greater than 50% savings, even considering that the total installed power of a multi-wire cutter is greater than that of a traditional loom.
The Multiple Diamond Wire Cutter is the alternative to the primary sawing methods currently used, improving the production capacity quantitatively, efficiently taking advantage of the energy resources necessary for the production of materials and significantly reducing waste produced during the cutting phase.
Comparatively, the advantages of using this new technology applied to the multiwire cutter are obvious. The multi-wire cutter can cut any type of stone material in front of looms that only cut granites or marble, but these are two different models and that use different tools, the looms are only profitable when cutting 2-3 cm sheets of thickness, but its biggest disadvantage is in the energy consumption and the very high production of solid waste, since the water used is recovered in all cases, this waste apart from assuming a higher purification cost, presents a problem of environmental pollution in case of the looms because it contains iron, and the lime that alters the acidity of the waters, in addition to the moment it is not possible to separate or recover at this stage of the process. There is an important difference compared to traditional cutters, which is based on the cutting height, with a disc we can cut 1.50 meters in front of the diamond wire that any commercial block can cut, apart from the great productive difference that exists
The water treatment and purification process for this new process is therefore more economical and less complex.
It is also worth noting that the water needs, while being similar, with respect to the traditional loom, the diamond wire cutting practically cancels the need to wash the load after sawing, this being much less demanding and both the needs and Water losses during the cutting process are lower.
Another aspect to note is that the multi-wire cutter, for an equivalent capacity, the effective energy consumption, is lower compared to any of the methods used. This translates into significant energy savings both in the implementation, as in production costs
With respect to consumables, say that in the multi-thread cutter there is only one; the diamond wire, small volume, easy storage and simple supply. The costs derived from storage, stock programming and handling, are also lower with respect to strapping, shot and lime, necessary for the traditional loom.
In reference to the costs of implementation, the simplicity and the consequent lower cost of civil works stand out in the first place, while in the loom the necessary work constitutes an indispensable part of it, in the multi-wire cutter, this becomes a mere support of it. In addition, in the case of renewal or replacement of the machine, the loom forces the new implantation to be exactly the same model as the previous one, while in the case of the multi-threaded cutter there is a high degree of possibilities of being able to make an adaptation of the existing civil works. In any important case, that is, the space occupied by the multiwire is less.
The simplicity of the multiwire is significantly greater, both in installation, use and handling, as well as in maintenance, both mechanically and electrically. It is important to note that the NDF-6870/60 multi-wire cutter does not use the common solution for vertical movement consisting of a central motor with reducer, transmissions and angular forwarding. This is replaced by two independent and electronically synchronized servomotors without coupling between them. This solution, in effect, cancels the inconveniences of the classic mechanical transmissions, the clearances and possible breaks due to wear and fatigue, and also allows us greater flexibility in the movements to be carried out. In this regard, it should be noted that the system is capable of working atspeeds as slow as one millimetre per minute, as at the fastest of almost one meter per minute, all without loss of power or precision in movement.
As a practical effect, the NDF-6870/60 cutter is the fastest machine on the market capable of performing a vertical ascent movement against any contingency, avoiding the undesirable marks of diamond wire in the stone.
The surface of the final product serrated with the diamond wire, in addition to the fact that it does not need to be practically washed, much less the use of harmful acids or chemicals and dangerous handling, offers the important advantage that its surface state can be assimilated to a certain jaded In the event that the material must be subsequently polished, a certain reduction in the costs associated with the abrasives used in the polishing process and the consequent reduction in production times should be noted.
The high speed of the multiwire cutter will also allow new users of this technology to schedule production with a lower advance and greater flexibility than the loom, even allowing partially cutting a block and reserving the rest of it for another more appropriate time.
The flexibility of production is also given by the clearly lower staffing needs. The preparation of the saw in a thread cutter for a cut, consumes less than half the time and less than half of human resources than a traditional strapping loom
With this cutting unit it is intended to integrate the fully automated operation of the primary sawing work of the stone blocks, with the minimum human intervention and therefore a significant reduction in the manoeuvres of product handling, regularization and optimization of the work processes, the increase of the productive capacity thanks to the reduction of the cycle times and the efficient use of the dead times, the reduction of the energy consumption and the production of the waste during the cutting process, and finally the reduction of the associated risks for the personnel involved in the work of manipulation and mechanization of the materials throughout each working day

Why should our cutter be bought?
The use of diamond wire in the primary sawing work has been used in the sector for not many years, and said wire is applied on known machines, normally formed by two pulleys on which a wire is installed forming a closed loop with which the cuts are made on the stone blocks.

In recent years, machines have begun to be used that use several diamond threads, which are mounted on multi-channel drums or formed by several pulleys, on which several threads are mounted in order to make several cuts at the same time on the stone blocks, thus obtaining significant productions.

The machines used up to now present different technical problems when performing the correct tensioning and control of the thread loops, in addition to another more significant one that lies in the possibility of varying in a simple way the position of the pairs of wires in order to obtain different thicknesses or vary them in the production of boards.

Taking these disadvantages into consideration, the N.6860/60 cutter stands out for its simplicity in the individual tensioning device of the tension wheels, and at the same time the variation of processing thicknesses in the slabs and boards to be cut has been simplified in a simple and easy way.

NODOSAFER offers its customers in addition to all the features intrinsic to any thread machine, such important improvements as:

Architecture based on a robust and compensated structure to avoid vibrations.
Maximum protection against the penetration of water and dust in the most sensitive parts.
Large diameter helical ball screws in the vertical movement for a smooth and precise displacement.
Linear roller recirculation guides in the columns to guarantee the absolute verticality of the cut.
Servo motors synchronized by software in the vertical movements that ensure smoothness in the cutting, low consumption, maximum precision and avoid the gaps and problems of the central motorization with transmission and forwarding.
Basic large diameter drive drum mechanism that prolongs the life of the thread.
Automatic tensioning device by independent pulleys of each of the threads, with position, arrow and tension control of each of the threads.
Automatic and progressive decrease of speed in case of excessive arrow in the thread.
Detection of thread breakage and controlled stop (rapid braking and maximum speed climb)
Controlled emergency stop to avoid marks on the cut block.
Possibility to resume a cut in automatic or semi-automatic mode.
Wide range of devices and program functions for operator and machine safety.
Motorized trolley with optional position control.
Operator panel in color with great ease of use and multiple configuration possibilities.
Compact electrical panel with the latest technologies.
High power main motor driven by inverter.
Button pad for movements in manual mode.
Automatic greasing.
Security
NODOSAFER machines are protected and provide a safety lock around their entire perimeter in accordance with CE safety standards
Load block trolleys
The machine has 2 motorized block trolleys fitted as standard.

Karann Multi Wire Saw Machine
Our different machine models between 10-36 wires
Made by Turkey
There are 3 different versions of our machine
5 wire 2 cm slabs
10 wire min 5 cm slabs (for thick stone with separate hoops each)
36 wire 2 cm slabs
