SMERALDA GLX 300 PROFESSIONAL 2-AXES CUTTING MACHINE
FOB Price:
Type:
Stone Factory MachinesStone Slab Cutting MachinesCNC Bridge Cutting Machine
Usage:
Granite, Marble, Limestone, Slate, Sandstone
After-Sale
Warranty:12 Months
Supplier
Eatablished :Dec 31,2000
Main Product:
CNC-Numerical Control Machining Centres- Floor Honing Machines- Water-Jet Cutting Machines -Block Cutting Machines-Cutters|
You may also like
Machinery Function Features
Sawing machine especially suitable for small/medium-sized marble worshops.
Side supports and working head based on spheroidal graphite iron to avoid any vibrations.
The machine's bridge is fixed and the head can be tilted for cuts at a 45° angle, manual depth adjustment (motorized on request). Moreover, the working unit feed is motorized (adjustable speed) and slides on linear guides with rolls, the transmission is achieved by means of an endless screw. The machine is equipped with marine wood working bench.
Technical Data
Parameters |
Unit |
SMERALDA GLX 300 |
Horizontal stroke(X axis travel) |
mm |
3100 |
Max.length of the cut slab |
mm |
3100 |
Max. revolutions of the spindle unit |
r/min |
2800 |
Disc diameter |
mm |
400 |
Blade hole |
mm |
40 |
Machine width |
mm |
1050 |
Head motor power |
kw |
5 |
Machine height |
mm |
1600 |
Approximate weight without table |
Kg |
850 |
Max. workable thickness |
mm |
110 |
Machine length |
mm |
4140 |
Head raising/lowering stroke(Z axis travel) |
mm |
200 |
Spindle diameter |
mm |
30 |
Voltage |
v |
230/400 |
